Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-116
Programmable Squeegee Assembly 1005488 Parts Listing
Key # Part # Description Quantity
1 1004585 COVER, PROHEAD 1
2 1003312-2 ASSEMBLY, MOTOR, SQUEEGEE DOWN 1
3 1001636 CLEVIS, ROD(MODIFICATION) 2
4 1001801 BRAKE, PROHEAD 1
5 1001838 LOCKNUT, BEARING, M6 1
6 A2-1101-P1 BLOCK, PRESSURE PLATE ADJUSTMENT, RIGHT 2
7 A2-1101-P2 BLOCK, PRESSURE PLATE ADJUSTMENT, LEFT 2
8 A2-1102-P1 COVER, PRESSURE PLATE BLOCK, RIGHT 2
9 A2-1102-P2 COVER, PRESSURE PLATE BLOCK, LEFT 2
10 A2-1203 NOSE, CYLINDER 1
11 A2-1260 BLOCK, BEARING 1
12 A2-1261 PLATE, RETAINING 1
13 A2-1431 WASHER, PRECISION, .237" ID X .500" OD X .125" THICK 1
14 A2-1554 BALLSCREW/BALLNUT ASSEMBLY 1
15 A2-697 BAR, SWING ARM 1
16 1005005 PLATE, FRONT, ASSEMBLY 2
17 A2-700 MOUNT, BEAM SPRING 1
18 A2-701 CLAMP, BEAM SPRING 1
19 A2-702 SHAFT, LEFT BEARING 1
20 A2-705 PLATE, PRESSURE 2
21 A2-706 PLATE, PUSHER 2
22 A2-708 PLATE, TOP 2
23 A2-710-P1 CRANK, CAM FOLLOWER 1
24 A2-710-P2 CRANK, CAM FOLLOWER 1
25 A2-711-P1 MOUNT, BEARING 1
26 A2-711-P2 MOUNT, BEARING 1
27 A2-712 MOUNT, TOGGLE CYLINDER 2
28 A2-713 SHAFT, CAM CRANK 2
29 A2-714 BLOCK, TOGGLE STOP 2
30 A2-718 CONNECTOR, CYLINDER SHAFT 2
quantities are of entire assembly
NS not shown
Illustrated Parts Breakdown
1-117
31 A2-719 MOUNT, CYLINDER 2
32 A2-720 PLATE, CYLINDER MOUNT 4
33 A2-723 PLATE, END 2
34 A2-724-P1 MOUNT, BEARING 1
35 A2-724-P2 MOUNT, BEARING 1
36 A2-725 PLATE, MAIN MOUNTING 1
37 A2-726 MOUNT, BEARING PLATE 1
38 A2-727-P1 MOUNT, MOVING BEARING 1
39 A2-727-P2 MOUNT, MOVING BEARING 1
40 A2-728 MOUNT, MOTOR 1
41 A2-734 MOUNT, NUT 1
42 A2-737 ASSEMBLY, BLOCK, RIGHT SIDE 2
43 A2-775 FLAG, PROXIMITY SWITCH 1
44 A2-783 SHAFT, MAIN 2
45 A2-825 PLATE, MECHANICAL STOP 2
46 A2-826 SHAFT, SWING ARM 1
47 A2-827 SPACER, TOGGLE CYLINDER 2
48 A2-828 BLOCK, ASSEMBLY, LEFT SIDE 2
49 A2-829 HOUSING, BEARING 4
50 A2-831-P1 PLATE, DETENT, RIGHT 1
51 A2-831-P2 PLATE, DETENT, LEFT 1
52 A2-832-P1 MOUNT, ZERO WEIGHT SENSOR, RIGHT 1
53 A2-832-P2 MOUNT, ZERO WEIGHT SENSOR, LEFT 1
54 A2-833 PLATE, NUT 1
55 1004128 CLAMP, SQUEEGEE, ASSEMBLY 2
56 A2-856 MOUNT, BALANCE CYLINDER 2
57 A2-859 PLATE, TRACTION 4
58 A2-866 ASSEMBLY, SHAFT, RIGHT BEARING 1
59 A2-867 CLAMP, BAR, SWING ARM 1
60 A2-868 MATERIAL, TRACTION 4
Programmable Squeegee Assembly 1005488 Parts Listing (continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-118
61 A2-869 PIN, TOGGLE CYLINDER 2
62 P0180 BEARING, RADIAL, .375" ID X .875" OD X .2188" W 4
63 P0183 SWITCH, PROXIMITY 1
64 CLAMP, WIRE AND CABLE, NYLON, DIA. 1/2" 1
65 P0423 CLAMP, WIRE AND CABLE, NYLON, DIA. 3/8" STYLE A 1
66 1001525 COVER, STATIC, UP2000 1
67 P6135 WASHER, CURVED, SPRING, .203"ID X .322"OD X 1.75" 2
68 P1243 RETAINING RING 2
69 P1714 FITTING, PLASTIC, ELBOW, 10-32 THREAD 4
70 P1476 BEARING, SUPER 8 4
71 P1477 RETAINING RING 8
72 P1590 WASHER 2
73 P1591 SWING ARM BEARING 2
74 P1594 BEARING, LINEAR 2
75 P1597 WASHER 4
76 P1598 CLAMP MODULE 4
77 1004645 BRACKET, HINGE, PROHEAD COVER 2
78 P1602 CYLINDER, AIR 2
79 P1606 MOTOR COUPLING 1
80 P1608 BEARING, SLEEVE, BRONZE, 1/4" ID X 5/16" OD X 1/4" 4
81 P1623 SCREW, SET, NYLON TIP, 4-40 X 5/32" LG. 1
82 P1682 WASHER, STEEL, .500" OD X .189" ID X .015"THICK 2
83 P1811 CYLINDER, RODLESS, .627" BORE, .50" STROKE 2
84 P1817 RETAINING RING, EXTERNAL, 5/32" NOMINAL SHAFT 4
85 P1819 PLUNGER, BALL, S.S. BODY, 1/4-20 THREAD 4
86 P1820 PLUNGER, BALL, S.S. BODY, 8-32 THREAD, DELRIN BAL 4
87 P1832 PLUNGER, BALL, S.S. BODY, HEAVY FORCE (GOLD) 10-32
THREAD
2
88 P1834 CYLINDER, RODLESS, W/1/8" NPT, RIGHT ANGLE FITTING 2
89 P2169 BEARING, BALL, THRUST-ANGULAR CONTACT 1
Programmable Squeegee Assembly 1005488 Parts Listing (continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
