Illustrated Parts Breakdown 1-131 Ultra Wiper Assembly 1006005 Parts Listing Key # Part # Description Quantity 1 1002211 PLA TE, MAIN WIPER, LEFT 1 2 1002110 BLOCK, PLENUM MOUNTING, LEFT 1 3 P4550 CYL,SIDE MOUNT , .56&qu…
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-130
Ultra Wiper Assembly 1006005 (1 of 1)
55
38
37
69
70
56,83
20
50
13
52
39
3
4
45
7
24
26
30
31
49
2
54
65
8
18
67
62
60
35
65
66
53
56,83
46
21
92
91
22
23,88
37
83
10
5
12
48
28
82
11
71
73
74
75
76
6
63
87
44
25
1
59
58
58
40,90
14
41
47
61
58
59
67
85,86
58
1006005
51
9
15
72
81,88,89
27
93
91
95
17
58
A
68
36
43
19
58
32
61
A
79
78
42
29
16
57
58
94
94
61
2
3
59
64
4
B
B
C
C
39
Front of
Printer
Illustrated Parts Breakdown
1-131
Ultra Wiper Assembly 1006005 Parts Listing
Key # Part # Description Quantity
1 1002211 PLATE, MAIN WIPER, LEFT 1
2 1002110 BLOCK, PLENUM MOUNTING, LEFT 1
3 P4550 CYL,SIDE MOUNT, .56" BORE X .62" STROKE 2
4 002056 CLEVIS, MAIN CYLINDER 2
5 1002212 PLATE, MAIN WIPER RIGHT 1
6 1005957 BLOCK, RIGHT PLENUM MOUNTING 1
7 1002112 CHAMBER, VACUUM 1
8 1000692 SHAFT, SHORT 1
9 A2-1315 MOUNT, FIXED SHAFT 1
10 1002584 MOTOR, 24DC, GEAR RATIO 1108:1 1
11 A2-1314 BLOCK,BEARING 1
12 1002116 GUARD, CHAIN 1
13 1002528-12
1002528-15
1002528-18
ASSY, SOLVENT TUBE,12INCH
ASSY, SOLVENT TUBE,15 INCH
ASSY, SOLVENT TUBE,18 INCH
1
14 1002161 FITTING, SOLVENT BAR END 1
15 1002160 ASSY, FLIP BAR 1
16 1000693 SHAFT, LONG 1
17 1006217 END CAP, DRIVE SHAFT 1
18 1000693 SHAFT, LONG 1
19 1002196 SHAFT, PAPER ROLLER 1
20 1002444 MOUNT, ROLL, SUPPLY 1
21 1000171 BRAKE, PAPER SUPPLY STENCIL WIPER 1
22 P4729 BUSHING, 1/2" X 3/8" X 3/8" LG 4
23 1001007 SHAFT, BREAK ASSY 1
24 1002130 RESERVOIR, SOLVENT 1
25 1002204 MOUNT, CYLINDER 1
26 1002207 MANIFOLD, FRONT 1
27 1002776 PIN, CLEVIS 1
28 1002216 MAINIFOLD, CABLE CARRIER MOUNT 1
quantities are of entire assembly
NS not shown
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-132
29 1002213 BAR, REAR WIPER 1
30 1005595 MOUNT, PAPER PRESENT SENSOR 1
31 CA-540 CABLE ASSY, STENCIL WIPER EMPTY, SENSOR 1
32 1006082 TRAY, PAPER GUIDE, RETROFIT VERSION 1
33 1005943 SUPPORT, ROLLER,LEFT 1
34 1005944 SUPPORT, ROLLER,RIGHT 1
35 1002445 MOUNT, FIBER OPTIC, HEAD 1
36 1002474 DRAIN COCK (MODIFIED) 1
37 P4173 FITTING, BARB, 5/8" TU X 1/2" NPT BRASS 6
38 1002214 MOUNT, CABLE CARRIER, MOVING 1
39 P3292 FITTING ELBOW 5/32" TUBE, 10/32 MALE 6
40 P5074 FITTING, 10-32 ML TO .170" BARB 3
41 P50S2 CYL 9/16" BORE X 1/2" STROKE DBL ACTING, PIVOT
MOUNT
1
42 P5230 MOD, ROD END .19" ROD X 8-32 ML 1
43 P2034 HOSE, BARB 1
44 1002232-12,
-15,-18
PLENUM, 12INCH,15 INCH,181NCH 1
45 1002542 MOUNT, ROLLER, RIGHT 1
46 1002555 MOUNT, ROLLER, LEFT 1
47 1002818 GUIDE ROD, REMOVABLE 1
48 1001244 GEAR, SPROCKET MOD 2
49 P5122 FIBER SENSOR HEAD 1
50 CA-515 ANALOG SENSOR, INFA- REDCABLE, FIBER OPTIC SENSOR,
(ASSY)
1
51 P1486 CARDBOARD CORE 1
52 1002599 DRIVE SHAFT STENCIL WIPER VACUUM STENCIL WIPER 1
53 P2112
P5479
P1485
PAPER ROLL12INCH
PAPER ROLL15INCH
PAPER ROLL12INCH
1
54 P3619 PLUNGER, HAND RETRACTABLE 1
Ultra Wiper Assembly 1006005 Parts Listing (continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
