Ultraprint 2000 Hi

Series Illustrated Parts Breakdown/Engineering Drawings

1-132

29 1002213 BAR, REAR WIPER 1

30 1005595 MOUNT, PAPER PRESENT SENSOR 1

31 CA-540 CABLE ASSY, STENCIL WIPER EMPTY, SENSOR 1

32 1006082 TRAY, PAPER GUIDE, RETROFIT VERSION 1

33 1005943 SUPPORT, ROLLER,LEFT 1

34 1005944 SUPPORT, ROLLER,RIGHT 1

35 1002445 MOUNT, FIBER OPTIC, HEAD 1

36 1002474 DRAIN COCK (MODIFIED) 1

37 P4173 FITTING, BARB, 5/8" TU X 1/2" NPT BRASS 6

38 1002214 MOUNT, CABLE CARRIER, MOVING 1

39 P3292 FITTING ELBOW 5/32" TUBE, 10/32 MALE 6

40 P5074 FITTING, 10-32 ML TO .170" BARB 3

41 P50S2 CYL 9/16" BORE X 1/2" STROKE DBL ACTING, PIVOT

MOUNT

42 P5230 MOD, ROD END .19" ROD X 8-32 ML 1

43 P2034 HOSE, BARB 1

44 1002232-12,

-15,-18

PLENUM, 12INCH,15 INCH,181NCH 1

45 1002542 MOUNT, ROLLER, RIGHT 1

46 1002555 MOUNT, ROLLER, LEFT 1

47 1002818 GUIDE ROD, REMOVABLE 1

48 1001244 GEAR, SPROCKET MOD 2

49 P5122 FIBER SENSOR HEAD 1

50 CA-515 ANALOG SENSOR, INFA- REDCABLE, FIBER OPTIC SENSOR,

(ASSY)

51 P1486 CARDBOARD CORE 1

52 1002599 DRIVE SHAFT STENCIL WIPER VACUUM STENCIL WIPER 1

53 P2112

P5479

P1485

PAPER ROLL12INCH

PAPER ROLL15INCH

PAPER ROLL12INCH

54 P3619 PLUNGER, HAND RETRACTABLE 1

Ultra Wiper Assembly 1006005 Parts Listing (continued)

Key # Part # Description Quantity

quantities are of entire assembly

NS not shown

Illustrated Parts Breakdown

1-133

55 1002554 ASSY, CABLE CARRIER 18 LINKS 1

56 P5086 HOSE,.518"ID X .906" OD. STEEL WIRE REINFORCED 51 IN.

57 1002195 ROLLER, PAPER 1

58 8-32 X 3/8" SHCS —

59 6-32 X 1/2" SHCS —

60 P2711 SCREW, SHOULDER 2

61 1006089 SUPPORT, ROLLER 2

62 10-32 X 3/8" SHCS —

63 6-32 X 1" SHCS —

64 8-32 X 3/8"SHCS —

65 6-32 X 3/8" SHCS —

66 #6 FLAT WASHER —

67 8-32 X 1/2" SHCS —

68 8-32 X 7/8" SHCS —

69 1/4-20 X 1/4" FHS —

70 10-32 X 5/8" SHCS —

71 #10 FLATWASHER —

72 8-32 X 1" SHCS —

73 M3 X 10MM SHCS —

74 1/4 -20 X 1 1/2" SHCS —

75 8-32 X 1 1/2" SHCS —

76 #8 FLAT WASHER —

78 1000841 ROLLER, PAPER, LONG 1

79 1000840 ROLLER, PAPER, SHORT 1

80 P6595 BEARING, BRONZE, FLANGED 6

81 A2-1313 SHAFT, SUPPORT, SPROCKET 1

82 P5206 FITTING, HEX PLUG 1

83 P5461 CLAMP, HOSE, 1/2" TO 29/32" WORM GEAR TYPE 6

84 P2346 BEARING, FLANGED,1/2" OD. X 3/8" ID. X 1/2" 2

85 1002425 CHAIN, ROLLER DRIVE 1

Ultra Wiper Assembly 1006005 Parts Listing (continued)

Key # Part # Description Quantity

quantities are of entire assembly

NS not shown

Ultraprint 2000 Hi

Series Illustrated Parts Breakdown/Engineering Drawings

1-134

86 P2091 LINK, CONNECTING 1

87 P4738 O-RING 5/8" OD X .070" W 2

88 P1243 RETAINING RING 4

89 P1590 WASHER 2

90 P3739 O-RING, .228" ID. X .040" W2 2

91 1001623 SPRING, COMPRESSION, MODIFIED 1

92 10-32 X 1/2" BHS —

93 P0050 WASHER, 13/16" ID. X 1/2" OD. X 3/32" W 2

94 8-32 X 1/4" BHS —

95 8-32 X 3/8" SHCS —

96 8-32 X 3/4" SHCS —

97 10-32 X 3/4" SHCS —

Ultra Wiper Assembly 1006005 Parts Listing (continued)

Key # Part # Description Quantity

quantities are of entire assembly

NS not shown
