Illustrated Parts Breakdown 1-135
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-134
86 P2091 LINK, CONNECTING 1
87 P4738 O-RING 5/8" OD X .070" W 2
88 P1243 RETAINING RING 4
89 P1590 WASHER 2
90 P3739 O-RING, .228" ID. X .040" W2 2
91 1001623 SPRING, COMPRESSION, MODIFIED 1
92 10-32 X 1/2" BHS —
93 P0050 WASHER, 13/16" ID. X 1/2" OD. X 3/32" W 2
94 8-32 X 1/4" BHS —
95 8-32 X 3/8" SHCS —
96 8-32 X 3/4" SHCS —
97 10-32 X 3/4" SHCS —
Ultra Wiper Assembly 1006005 Parts Listing (continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
Illustrated Parts Breakdown
1-135
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-136
Board Transport Tracks Assembly OPT03/OPT04 (1 of 1)
10
9
8
7
6
4,5
2
3
1
See Above
OPT03/04
1
4
1
5
These parts are installed
on each end of both Tracks
