Ultraprint 2000 Hi E Series Illustrated Parts Breakdown/Engineering Drawings 1-146 Environmental Control Assembly APOPT 29 (1 of 1) FRONT LEFT FRONT LEFT OPT29_1 5,6 Rear Door P anel 4 1 3 1 2 2
Illustrated Parts Breakdown
1-145
Auto Width Conveyor Assembly APOPT 20 Parts Listing
Key # Part # Description Quantity
1 001615 PLATE, TRACK WIDTH 1
2 A2-1374 PLATE, AUTO TRACK WIDTH 1
3 1002045 TRACKS, PROXIMITY SWITCH BRACKET 1
4 1002243 FLAG, TRACKS PROXIMITY 1
5 1003312-1 ASSEMBLY, MOTOR, AUTO TRACK WIDTH 1
6 CA-197-13 CABLE, PROXIMITY SWITCH 1
7NS CA-232-10 CABLE, MOTOR, EXTENSION, TRACK WIDTH 1
8 A2-1273 SWITCH, PROXIMITY 1
9 P0795 PULLEY, TIMING 1
10 P0989 SENSOR, PROXIMITY 1
11 P3311 BELT, TIMING 1
12 FITTING, BARB 10-32 X 5/64" ID 3
quantities are of entire assembly
NS not shown
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-146
Environmental Control Assembly APOPT 29 (1 of 1)
FRONT LEFT
FRONT LEFT
OPT29_1
5,6
Rear Door Panel
4
1
3
1
2
2
Illustrated Parts Breakdown
1-147
Environmental Control Assembly APOPT 29 Parts Listing
Key # Part # Description Quantity
1 001545 DEFLECTOR, AIR 2
2 A2-1462 PLATE, HOSE ADAPTER 1
3 1000151 ASSEMBLY, TEMPERATURE CONTROLLER 1
4 1000152 ASSEMBLY, RH TEMPERATURE SENSOR 1
5 P4465 ECU, 60 HZ, W/O HUMIDITY CONTROL 1
6 990211 KIT, PANELS, ECU 1
quantities are of entire assembly
NS not shown
