Ultraprint 2000 Hi

Series Illustrated Parts Breakdown/Engineering Drawings

1-158

Vacuum Stencil Wiper Assembly OPT52 Parts Listing

Key # Part # Description Quantity

APOPT 52 ASSEMBLY PARTS LISTING

1** 1002564 MOUNT, VACUUM PUMP 2

2** 1002664 BRACKET, EXHAUST MOUNT 1

3** 1003145 BRACKET, SEC. REGULATOR 1

4** P3360 VALVE, 4-WAY 3

5** P5225 SCREW, M4 X 20MM STEEL HEAD HEX 4

6** P5557 LINK, CABLE CARRIER 4

7 P6294 PUMP, DIAPHRAGM 1

8 P6294 10-32 X 1/2" SHCS —

9 #10 FLAT WASHER —

10 10-32 X 5/8" SHCS —

11 8-32 X 3/8" SHCS —

990350 PARTS LISTING (PART OF APOPT 52)

2 P6829 FILTER, VACUUM, 3/4" POLYPROPYLENE 2

3 P5087 GAUGE, VACUUM, 0-30 HG, 0-100 KPA, 1/8" NPT 1

4 P5089 PUMP, VACUUM 1

5 P5093 VALVE, 3-WAY, 3/8" NPT 1

6 P5162 FITTING, PIPE NIPPLE, 3/4" NPT 2

7 P5188 FITTING, MALE ELBOW, 3/8" NPT TP 1/2" TUBE 1

8 P5206 FITTING, HEX PLUG, 3/8" NPT 1

9 P5396 FITTING, ELBOW, 3/8" NPT FEMALE 1

10 P5397 FITTING, 1-1/2" NIPPLE, 3/8" NPT 1

11 P5439 FITTING, CLOSE NIPPLE, 3/8" NPT X 1" LG 1

12 P5086 HOSE, 5/8" ID. X .90 65.0 IN.

13 P5160 FITTING, MALE ELBOW 2

14 P5187 FITTING, MALE ELBOW 1

15 P5205 FITTING, ELBOW, 5/8" TO 1/2" NPT 2

16 P5461 CLAMP, HOSE, SS 1/2" 4

17 P5164 FITTING, 5/8" HOSE TO 3/4" NPT FM 2

18 P5208 MUFFLER, VACUUM 2

20 P5495 SCREW, MOUNTING, VACUUM 4

21 10-32 X 7/8" SHCS —

22 #10 FLAT WASHER —

quantities are of entire assembly

NS not shown

Illustrated Parts Breakdown

1-159

990352 PARTS LISTING (PART OF APOPT 52)

1 1002078 MOUNT, BEARING, LEFT 1

2 001499 BLOCK, RIGHT MOUNTING 1

3 P5449 STANDOFF, 3/16" RD X 5/8", M/F, 6-32,SS 4

4 1002464 BRACKET, CABLE CARRIER MOUNT, FIXED 1

5 1001602 COVER, DRIVE CARD, PAPER WINDER MOTOR, VAC 1

6 001518 BRACKET, SENSOR MOUNT 1

7 001519 FLAG, LOCKING POSITION 1

8 001527 BLOCK, LOCKING 2

9 1004312 BLOCK, LOCK PIN, RIGHT 1

10 1004313 BLOCK, LOCK PIN, LEFT 1

11 001530 SUPPORT, LOCKING BLOCK 2

14 1002763 DECAL, PAPER ROUTING 1

15NS P5556 DRIVER, MOTOR, PWM, ANALOG OUTPUT 1

19 P2700 PHOTOMICROSENSOR 1

21 P3382 RAIL, LINEAR, MINI 2

22 1000150 SLIDE, BEARING (MODIFICATIONS) 2

23 P3386 PLUNGER, STAINLESS DELRIN BALL, .078" DIA. 4

30 10-32 X 3/8" SHCS —

31 6-32 X 3/8" SHCS —

32 6-32 X 5/8" SHCS —

33 #6 FLAT WASHER —

34 M3 X 12MM SHCS —

35 4-40 X 3/16" BHS —

36 10-32 X 1/2" SHCS —

37 1/4-20 X 3/8" FHS —

40 #10 FLAT WASHER —

41 M3 X 10MM SHCS —

42 M3 X 3MM BHS —

43 6-32 X 1/4" BHS —

44 10-32 X 1-3/4" SHCS —

Vacuum Stencil Wiper Assembly OPT52 Parts Listing (continued)

Key # Part # Description Quantity

quantities are of entire assembly

NS not shown

Ultraprint 2000 Hi

Series Illustrated Parts Breakdown/Engineering Drawings

1-160

990497 CABLE KIT ASSEMBLY PARTS LISTING (PART OF APOPT 52)

NS CA-508 CABLE, ASSY WINDER SPEED CONTROL 1

NS CA-513-1 CABLE, ASSY WINDER 1

NS CA-514 CABLE, ASSY, EXT. -OPTIC SENSOR 1

NS CA-235-3 CABLE, WIPER PARK PROXIMITY SENSOR 1

NS CA-533-7 CABLE, ASSY, PAPER EMPTY 1

NS CA-539 CABLE, ASSY, PAPER SENSOR 1

NS CA-236-3 CABLE, WIPER PARK 1

N/S P5537 TUBING, POLYURETHANE 1/2" OD X .320" ID 76.0IN

45 P5556 DRIVER, MOTOR, PWM, ANALOG INPUT 1

46 4-40 X 1/4" SHCS

990512 ASSEMBLY PARTS LISTING (PART OF APOPT 52)

1 1003505 BRACKET, GAUGE 1

3 P7076 FITTING, TEE 1

4 P0375 REGULATOR, AIR ADJUSTABLE PRESSURE 1

5 P3577 TUBING, POLYETHYLENE 1/8" OD X .025" WALL 8.0IN

8 P7065 GAUGE, 0-160 PSI 1

9 P7075 FITTING, ELBOW 5/32" OD X 1/16" 2

11 10-32 X 3/8" SHCS —

12 #10 FLAT WASHER —

990355 ASSEMBLY PARTS LISTING (PART OF APOPT 52)

2 P6510 FITTING, ML ELBOW 1/2" NPT ML TO 1/2" TUBE 2

3 P7087 REGULATOR, W/GAUGE (P7066) (#6) 1

4 #10 FLAT WASHER —

5 10-32 X 5/16" SHCS —

Vacuum Stencil Wiper Assembly OPT52 Parts Listing (continued)

Key # Part # Description Quantity

quantities are of entire assembly

NS not shown
