Ultraprint 2000 Hi E Series Illustrated Parts Breakdown/Engineering Drawings 1-18 93 P3864 JUMPER , 6 POSITION 1 94 P4764 JUMPER , 10 POSITION 1 95 P2193-03 MARKER , STRIP, 21 THRU 30 1 96 P2193-02 MARKER , STRIP, 11 THR…
Illustrated Parts Breakdown
1-17
62 8-32 X 1/2" FHS —
63 #10 INTERNAL TOOTHED LOCK WASHER —
64 P0636 TERMINAL, WIRE, RING, SELF-ISUL, #10 STUD 1
65 10-24 NUT —
66 P3504 CHASSIS, COMPUTER 1
67 M3 X 0.5-6MM SHCS —
68NS P5975 CONNECTOR, 37 PIN 1
70 6/32 X 1-1/4" FHS —
71 P3809 BLOCK, TERMINAL END 2
72 P2220-15 MOUNTING RAIL, 15 INCH, LOW PROFILE 1
73 P3762 TERMINAL BLOCK, 4-POSITION 20
74 P3808 BLOCK, TERMINAL GND , 4-POSITION 2
75 P3766 COVER, TERMINAL BLOCK 1
76 P3760 BLOCK, TERMINAL FUSE 8
77 P3314 CLIP, RELAY, DIN RAIL ADAPTER 2
78 P0865 SOCKET, RELAY, 4-POLE 1
79 P3761 PLATE, FUSE BLOCK END 8
80 P0703 FUSE, 5A, SLO-BLO, 250V 2
81 P0887 FUSE, 2A, SLO-BLO, CERAMIC BODY 2
82 P1992 FUSE, 1A, 250V, GLASS BODY 1
83 P0867 CLIP, RELAY 2
84 P0864 RELAY, 3A, 4PDT, 24VDC, W/LIGHT 1
85 P3670 RELAY, 120VAC COIL 1
86 P2197 RELAY, MECHANICAL 1
87 P2199 SUPPRESSOR, DC RELAY COIL 1
88 P0695 DIODE, SILICON 1
89 P2193-01 MARKER, STRIP, 1 THRU 10 1
90 P0585 VARISTOR, METAL OXIDE, 175 VOLTS DC 2
91 P5151 MARKER, AC, YELLOW W/BLACK AC SYMBOL 4
92 P3860 JUMPER, 2 POSITION 2
Upper Drawer Assembly 990339 Parts Listing
(continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-18
93 P3864 JUMPER, 6 POSITION 1
94 P4764 JUMPER, 10 POSITION 1
95 P2193-03 MARKER, STRIP, 21 THRU 30 1
96 P2193-02 MARKER, STRIP, 11 THRU 20 1
97 P2193-00 MARKER, BLANK 8
98 P2558 FUSE, .25A, 250V, SLO-BLO, CERAMIC BODY 3
99 P5040 JUMPER, 3-POSITION, FUSEBLOCK 1
100NS P2930 TUBING, TEFLON 1
101 8/32 X 1/4" SHCS —
102 #8 FLAT WASHER —
103NS P0757-18 WIRE, WHITE/BLUE, 16AWG 45.0 IN.
104NS P0757-189 WIRE, GREEN/YELLOW, 16 AWG 65.0 IN.
105NS P0757-2 WIRE, RED, 16 AWG 100.0 IN.
106NS P0757-6 WIRE, BLUE, 16 AWG 45.0 IN.
107NS P0757-9 WIRE, WHITE, 16 AWG 75.0 IN.
108NS P0758-6 WIRE, BLUE, 18 AWG 100.0 IN.
109NS P0759-18 WIRE, WHITE/BLUE, 22 AWG 1,420.0 IN.
110NS P0759-6 WIRE, BLUE, 22 AWG 2,550.0 IN.
111NS P0913 CONTACT, PIN, 20-14 5
112NS P0914 CONTACT, SOCKET 5
113NS P0921 CABLE, INSTRUMENTATION, 22 GA 260.0 IN.
114NS P1283 SM-IDC5, MINI DC INPUT MODULE 51
115NS P1284 SM-ODC5, MINI DC OUTPUT MODULE 33
116NS P2071 LABEL, WIRE MARKER, WHITE 275
117NS P2263 CONTACT, SOCKET, 24-, MINI-FIT 2
118NS P2668 CONNECTOR, MTA-100 RECEPTACLE, 4 PIN, 22 AWG 13
119NS P0914 CONTACT, PIN, 24-20 CPC, SERIES 1 22
120NS P0921 CONTACT, PIN, 24-20 CPC, SERIES 1 127
121NS P3543 CONTACT,SOCKET, 24- AWG, SERIES 2 67
122NS P3548 CONTACT, PIN, 16-12 CPC, SERIES 3 2
Upper Drawer Assembly 990339 Parts Listing
(continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
Illustrated Parts Breakdown
1-19
123NS P3550 CONTACT, PIN/GND, 16 AWG,CPC, SERIES 3 1
124NS P3653 COVER, CLOSED-END, STRAIN RELIEF, 4-POS, MTA-1 13
125NS P4722 MINI OUTPUT MODULE 2
126NS P5083 JUMPER, COMB, 16 POS TERMINAL BLOCK 15
127NS P2303 TEST POINT, BLACK 1
128NS P3653 TEST POINT, RED 13
Upper Drawer Assembly 990339 Parts Listing
(continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
