Illustrated Parts Breakdown 1-31 32 P3762 TERMINAL BLOCK, 4-POSITION 9 33 P3808 BLOCK, TERMINAL GROUND, 4-POSITION 1 34 P2193-01 MARKER , STRIP, 1 THRU 10 1 35 P5151 MARKER , AC VOLTAGE, YELLOW W/BLACK A C 2 36 P1827 SWI…
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-30
Pneumatics Tray Assembly 990341 Parts Listing
Key # Part # Description Quantity
1 1002750 TRAY, PNEUMATICS 1
2 1002546 XT9 TERMINAL BLOCK ASSEMBLY 1
3 1002539 ASSEMBLY CONNECTOR, PNEUMATIC MODULAR PLUG-IN 1
4 P1411 POWER SUPPLY, 12VDC, UL, CSA, TUV APPROVED 1
5 P3512 CONNECTOR, CPC RECEPTACLE, 23-37 1
6 P0581 CONNECTOR, CPC RECEPTACLE, 17-14 2
7 P3508 CONNECTOR, RECEPTACLE, 17-3 1
8 P6072 KEYSWITCH, 2 POLE, 3 POSITION 1
9NS P2930 TUBING, TEFLON 2
10 P3662 BRACKET, MOUNTING 2
11 P3663 KIT, THREADED ROD 1
12 001362 COVER, POWER SUPPLY 1
13 002119 LABEL, CAUTION, ‘RISK OF SHOCK’ 1
14 P0979 LABEL, CAUTION, ‘RISK OF SHOCK’ 1
15 P0980 LABEL, ‘FUSE’ 1
16 #8 FLAT WASHER —
17 8-32 X 1/4" SHCS —
19 #8 LOCK WASHER, INTERNAL TOOTHED —
20 P0630 TERMINAL, WIRE, RING 1
22 8-32 X 1/4" BHS —
23 4-40 X 1/4" BHS —
24 P0911 CONNECTOR, PLUG, 6 CIRCUIT 1
25 P0912 CONNECTOR, CAP, 6 CIRCUIT 1
26 1005204 VALVE STACK ASSEMBLY 1
27 P3664 CONNECTOR, 2 PIN 13
28 P2220-06 RAIL, 6" MOUNTING 1
29 P3809 BLOCK, TERMINAL END 2
30 P3760 BLOCK, TERMINAL FUSE 4
31 P3761 PLATE, FUSE BLOCK END 4
quantities are of entire assembly
NS not shown
Illustrated Parts Breakdown
1-31
32 P3762 TERMINAL BLOCK, 4-POSITION 9
33 P3808 BLOCK, TERMINAL GROUND, 4-POSITION 1
34 P2193-01 MARKER, STRIP, 1 THRU 10 1
35 P5151 MARKER, AC VOLTAGE, YELLOW W/BLACK AC 2
36 P1827 SWITCH, PRESSURE, PNEU/ELECTRIC 1
37 P2193-00 MARKER, BLANK 4
38 P0586 VARISTOR, METAL OXIDE, 250VAC 1
39 P1992 FUSE, 1A, 250V, GLASS BODY 2
40 P0887 FUSE, 2A, 250V, SLO-BLO 1
41 P0778 FUSE, 1.25A, 250V 1
42 P3860 JUMPER, 2-PIN 2
43 P3656 MANIFOLD, HEADER 2
44 P0132 FITTING, PLUG, HEX COUNTER SUNK, 1/8" NPT 5
45 P6286 FITTING, BRANCH TEE, 1/2" TUBE X 1/4" NPT 1
46 P6287 FITTING, TEE, 1/4" TUBE X 1/4" NPT 1
47 P5870 FITTING, REDUCER, 5/32" TUBE X 1/4" TUBE 1
48 P1700 FITTING, PLUG, 1/4" OD 1
49 P3661 COVER, GASKET SCREW SET 10
50 P3660 VALVE, 4-WAY 3
51 P3294 FITTING, ELBOW, 5/32"OD X 1/8" NPT MINI 13
52 P2680 FITTING, ELBOW, 5/32" TUBE X 1/8" NPT MINI 8
53 P6285 FITTING, PLUG, 1/2" OD 1
54 P6276 BODY, MANIFOLD, 13 1
55NS P0452 BASE, CABLE TIE, ADHESIVE MOUNTING 6
56NS P0620 TIE, CABLE, SELF-LOCKING 60
57NS P0757-18 WIRE, WHITE/BLUE, UL1199, 16 AWG 9.0 IN.
58NS P0757-189 WIRE, GREEN/YELLOW, UL1199, 16 AWG 51.0 IN.
59NS P0757-2 WIRE, RED, UL1199, 16 AWG 61.0 IN.
60NS P0757-6 WIRE, BLUE, UL1199, 16 AWG 9.0 IN.
61NS P0757-9 WIRE, WHITE, UL1199, 16 AWG 50.0 IN.
Pneumatics Tray Assembly 990341 Parts Listing
(continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-32
62NS P0759-18 WIRE, WHITE/BLUE UL1199, 22 AWG 58.0 IN.
63NS P0759-6 WIRE, BLUE, UL1199, 22 AWG 293.0 IN.
64NS P0913 CONTACT, PIN, 20-14 5
65NS P0914 CONTACT, SOCKET, 20-14 5
66NS P3537 CONTACT, SOCKET, CPC, SERIES 1 12
67NS P3548 CONTACT, PIN, 16-12 CPC, SERIES 3 2
68NS P3550 CONTACT, PIN/GND, 16 AWG, CPC, SERIES 3 1
69NS P3577 TUBING, POLYURETHANE 378.0 IN.
70NS P3886 LABEL, SELF-LAMINATING 97
71NS P5981 CONNECTOR, 3-POSITION W/80 IN LEADS 14
Pneumatics Tray Assembly 990341 Parts Listing
(continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
