Ultraprint 2000 Hi E Series Illustrated Parts Breakdown/Engineering Drawings 1-38 Frame Kit Assembly 990109 (1 of 1) See IPB 990093 7 8 13 9 10 3 4 5 12 6 990109 1 2 11 14
Illustrated Parts Breakdown
1-37
Main Air Regulator Assembly 990395 Parts Listing
Key # Part # Description Quantity
1 P5091 FILTER, REGULATOR, 1 W/O GAUGE 1
2 P5253 JOINER SET, REGULATOR 1
3 P5399 JOINER SET, T BRACE, MAIN AIR REGULATOR 2
4 P5090 VALVE, SAFETY LOCK MANUAL OPERATION, 1/2" 1
5 P5257 FITTING, MALE ELBOW, 1/2" NPT ML TO 1/2" 2
6 P7066 GAUGE, PRESSURE 2" VACUUM PUMP GENERIC 1
7 P5092 FILTER, COALESCING MICRON 1
8 P5252 VALVE, EMERGENCY SLOW START 1
9 P5254 FITTING, HEX HEAD MOUNT, 3/8" NPT 1
10 P5415 FILTER, ELEMENT, COALESCING (FOR P5092) 1
11 P5416 FILTER, ELEMENT, FILTER/REGULATOR (FOR P5091) 1
quantities are of entire assembly
NS not shown
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-38
Frame Kit Assembly 990109 (1 of 1)
See IPB 990093
7
8
13
9
10
3
4
5
12
6
990109
1
2
11
14
Illustrated Parts Breakdown
1-39
Frame Kit Assembly 990109Parts Listing
Key # Part # Description Quantity
1 001603 BLOCK, PRINTHEAD CLAMP 4
2 1000342 SUPPORT, VISION PRINT 4
3 990114 THETA FRAME ASSEMBLY 1
4 990116 X FRAME ASSEMBLY 1
5 001335 Z-AXIS BASE CASTING 1
6 001350 CLAMP, ROD, Z-AXIS 1
7 990115 Y FRAME ASSEMBLY 1
8 001602 BLOCK, THETA CLAMP 4
9 10000679 SUPPORT, THETA VISION PRINT 4
10 990147 VISION FRAME ASSEMBLY 1
11 990513 PRINT FRAME ASSEMBLY 1
12 001355 MAIN BASE FRAME 1
13 3/8-18 X 1 1/4" SHCS —
14 3/8-16 X 1 3/4" SHCS —
quantities are of entire assembly
NS not shown
