Illustrated Parts Breakdown 1-55 96 001550 BRACKET, LEFT, BOARD TRACK SENSOR 1 99 P1001 PULNIX PHOTO PROXIMITY 2 100 6-32 X 1/4" BHS — Handling System Assembly 990108 Parts Listing (continued) Key # Part # Descripti…
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-54
37 A2-207 SHAFT, TENSION 1
38 A2-208 WHEEL, TENSION 1
39 10-32 X 1/4" BHS —
40 P0817 RING, RETAINING 1
42 001366 SHAFT, SPLINE 1
43 P3312 PULLEY, TIMING BELT 1
44 A2-1113 PULLEY, FRONT DRIVER 1
45 PIN, DOWEL, HARDENED 1
47 001616 PLATE, TRANSPORT MOTOR MOUNT 1
48 STUD, SELF-CLINCHING, SS, 10-32 4
49 P0386 STANDOFF, 3/8" HEX X 1.0" , F/F, 10-32, BRASS 3
50 8-32 X 3/8" SHCS —
52 P0809 ASSEMBLY, MOTOR, MODIFIED, BOARD TRANSPORT 1
53 10-32 X 1/2" SHCS 1
54 P0795 PULLEY, TIMING 3
55 P3311 BELT, TIMING 1
56 8-32 X 1/2" LOW HEAD SHCS —
57 6-32 X 5/8" SHCS —
59 001614 PLATE, RAIL SUPPORT 1
60 001336 SUPPORT, TRACKS 2
65 6-32 X 3/8" SHCS —
71 001617 TRACK, MOTOR MOUNT 1
72 001610 BEARING SUPPORT, RIGHT REAR 1
73 001609 NUT, PLATE, RIGHT 1
75 LEAD SCREW, RIGHT 1
80 A2-397 BRUSH, ANTI-STATIC CONVEYOR BELT 2
81 6-32 X 3/8" BHS —
83 P3301 HANDLE, CRANK 1
92 P3313 BELT, TIMING 1
94 001549 BRACKET, RIGHT, BOARD TRACK SENSOR 1
Handling System Assembly 990108 Parts Listing (continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
Illustrated Parts Breakdown
1-55
96 001550 BRACKET, LEFT, BOARD TRACK SENSOR 1
99 P1001 PULNIX PHOTO PROXIMITY 2
100 6-32 X 1/4" BHS —
Handling System Assembly 990108 Parts Listing (continued)
Key # Part # Description Quantity
quantities are of entire assembly
NS not shown
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-56
Z-Drive Assembly 990093 (1 of 2)
A
D
B
C
26
20
26
27
28
25
18
49
14
3
58
45
47
44
25
44
30
15
46
44
14
45
47
11
24
990093_1
Front of
Printer
