Illustrated Parts Breakdown

1-67

Printhead Assembly 990100 Parts Listing

Key # Part # Description Quantity

1 001399 PLATE, ATTACHMENT, NUT/CASTING 1

2 001407 BLOCK, BEARING 1

3 001408 BLOCK, BEARING 1

4 001409 MOUNT, MOTOR, SQUEEGEE 1

5 001410 MOUNT, MOTOR, BASE SQUEEGEE 1

6 001413 FLAG, MAIN DRIVE 1

9 001534 GUIDE, REAR, STENCIL 2

10 001533 ASSEMBLY, BRACKET, LEFT CLAMP MOUNT 1

11 001532 BRACKET, RIGHT CLAMP MOUNT 1

12 990113 ASSEMBLY, PRINTHEAD FRAME 1

13 A2-021 PLATE, RETAINING 1

14 A2-1278 PLATE, SPRING BAR MOUNTING 1

15 A2-1280 PLATE, SPRING BAR RESTRAINT 1

16 A2-1281 SPRING BAR, STENCIL 1

17 001539 SHAFT EXTENSION, CYLINDER 4

18 A2-1283 GUIDE, STENCIL, LEFT REAR 1

19 001544 STOP, STENCIL FRAME 1

20 A2-1295 GUIDE, STENCIL, LEFT 1

21 A2-1297 GUIDE, STENCIL, RIGHT 1

23 A2-248 NUT PLATE, Z SQUEEGEE 1

24 P0837 LOCKNUT, SN-00 1

25 P0839 NUT, BALL 1

26 P0846 BEARING, RADIAL 1

27 P0847 BEARING, RADIAL 2

28 P0848 COUPLING, THRU BORE 1

29 P0924 MOTOR, STEPPER 1

30 P1297-4 BRACKET, CABLE CARRIER 1

31 P1608 BEARING, PLAIN 2

32NS P2263 SOCKET, MOLEX, MINI-FIT 4

33NS P2266 HOUSING, SOCKET, MOLEX MINI-FIT, 4-POSITION 1

quantities are of entire assembly

NS not shown

Ultraprint 2000 Hi

Series Illustrated Parts Breakdown/Engineering Drawings

1-68

34 P2310 PHOTOMICROSENSOR, BUILT IN AMP, T-SHAPE 1

35 P2342 SPRING, COMPRESSION 2

36 P2344 SCREW, SHOULDER, 10-32 X 1 1/2 ", 3/8" DIA 1

37 P2358 WASHER, NYLON 2

38 P3294 FITTING, ELBOW 8

39 P3330 BEARING, LINEAR RAIL 1

40 P3331 BEARING, LINEAR RAIL 1

41 P3352 CARRIER, CABLE (19 LINKS) 1

42 P3380 CYLINDER, PANCAKE, 1.125" BORE X 1.25" STROKE 4

50 M3 X 16MM SHCS —

51 001414 HOUSING, BALL SCREW NUT 1

52 001416 SCREW, SQUEEGEE DRIVE BALL 1

53 990178 STANDARD PRINTHEAD SQUEEGEE ASSEMBLY 1

54 A2-193 INSERT, BEARING BLOCK 1

55 10-32 X 3/8" SHCS —

56 10-32 X 3/4" SHCS —

57 1/4-20 X 3/4" SHCS —

58 10-32 X 1/2" SHCS —

59 1/4-20 X 2 1/2" SHCS —

60 1/4-20 X 1 3/4" SHCS —

61 1/4-20 X 5/8" SHCS —

62 8-32 X 3/8" SHCS —

63 10-32 X 3/8" SHCS —

64 #10 FLAT WASHER —

65 4-40 X 1/4" SHCS —

66 10-32 X 2 1/8" SHCS —

67 #8 FLAT WASHER —

68 001438 BRACKET, IGUS, FRONT FIXED 1

69 001433 BRACKET, IGUS 1

72 8-32 X 3/8" BHS —

Printhead Assembly 990100 Parts Listing (continued)

Key # Part # Description Quantity

quantities are of entire assembly

NS not shown

Illustrated Parts Breakdown

1-69

73 10-32 X 7/8" SHCS —

74 10-32 X 5/8" SHCS —

75 1/4" FLAT WASHER —

76 8-32 X 1/2" BHS —

77 6-32 X 3/8" BHS —

78 10-32 X 1/2" BHS —

79 001603 BLOCK, PRINTHEAD CLAMP 4

80 3/8-16 X 1 3/4" SHCS —

81 100544 BAFFLE, STENCIL DEFLECTOR 1

82 10-32 X 3/4" SHCS —

83 M4 X 25MM SHCS —

84 10-32 X 2" SHCS —

85 10-32 X 1/4" BHS —

Printhead Assembly 990100 Parts Listing (continued)

Key # Part # Description Quantity

quantities are of entire assembly

NS not shown
