Ultraprint 2000 Hi E Series Illustrated Parts Breakdown/Engineering Drawings 1-72 31 001506 BRACKET, MOUNTING, Y IGUS TRACK 1 32 10-32 X 3/8" SHCS — 33 P3379 ASSEMBLY , CABLE TRACK 1 34 4-40 X 1/4" FHS 2 35 001…

Illustrated Parts Breakdown

1-71

Vision Gantry Assembly 990112 Parts Listing

Key # Part # Description Quantity

1 001500 GANTRY, VISION (MACHINED) 1

2 P3378 BEARING, LINEAR RAIL 1

3 M3 X 16MM SHCS —

4 P3376 KIT, BEARING SUPPORT 1

5 M4 X 20MM SHCS —

6 001502 BLOCK, BEARING FRONT X BALL SREW 1

7 10-32 X 5/8" SHCS —

8 P3375 ASSEMBLY, BALL SCREW & NUT 1

9NS 990250 KIT, VISION CABLE 1

10NS CA-200 CABLE, LAMPS, VISION 1

11NS CA-232-1 CABLE, MOTOR, EXTENSION, VISION X 1

12NS CA-233 ASSEMBLY, CABLE, 3D INSPECT 1

13NS CA-235-1 CABLE, VISION-X (+) PROXIMITY SENSOR 1

14NS CA-235-2 CABLE, VISION-X (-) PROXIMITY SENSOR 1

15NS CA-236-1 CABLE, VISION-X (+) PROXIMITY SENSOR, EXTENSION 1

16NS CA-236-2 CABLE, VISION-X (-) PROXIMITY SENSOR, EXTENSION 1

17NS CA-473 ASSY, CABLE, BOARD STOP, EXTENSION IN CAMERA, 2K 1

18 10-32 X 1/2" SHCS —

19 001494 BLOCK, VISION PROBE MOUNTING 1

20 M4 X 16MM SHCS —

21 M5 X 16MM SHCS —

22 001507 FLAG, X-POSITION LIMIT SWITCH 1

23 #6 FLAT WASHER —

24 6-32 X 3/8" BHS —

25 001526 FLAG, X-POSITION LIMIT 1

26 001508 BRACKET, X IGUS TRACK 1

27 6-32 X 3/8" FHS —

28 001488 BRACKET, X-POSITION SENSOR MOUNTING 2

29 P2700 PHOTOMICROSENSOR, SLIM, LIGHT ON/DARK ON 2

30 4-40 X 1/4" SHCS —

quantities are of entire assembly

NS not shown

Ultraprint 2000 Hi

Series Illustrated Parts Breakdown/Engineering Drawings

1-72

31 001506 BRACKET, MOUNTING, Y IGUS TRACK 1

32 10-32 X 3/8" SHCS —

33 P3379 ASSEMBLY, CABLE TRACK 1

34 4-40 X 1/4" FHS 2

35 001496 COVER, VISION GANTRY 1

36 6-32 X 1/4" BHS —

37 P6497 COUPLING, FLEX MOTOR —

38 1005804 MOTOR, VISION (X), MODIFICATION, ASSEMBLY 1

39 1005869 LABEL, LUBRICATION, STABURAGS 1

40NS 1005875 LABEL, LUBRICATION, ALVANIA 1

41 AP-20-87 ASSEMBLY, VISION PROBE 1

42 P3379 ASSEMBLY, CABLE TRANSPORT 1

Vision Gantry Assembly 990112 Parts Listing (continued)

Key # Part # Description Quantity

quantities are of entire assembly

NS not shown

Illustrated Parts Breakdown

1-73
