Ultraprint 2000 Hi E Series Illustrated Parts Breakdown/Engineering Drawings 1-74 Vision Frame Assembly 990087 (1 of 1) 990087 35 31 39 35 32 See IPB 990112 Vision Gantry Assy 33 34 36 37 38 3 15 11 25 13 19 4 13 7 10 41…
Illustrated Parts Breakdown
1-73
Ultraprint 2000 Hi
E
Series Illustrated Parts Breakdown/Engineering Drawings
1-74
Vision Frame Assembly 990087 (1 of 1)
990087
35
31
39
35
32
See IPB 990112
Vision Gantry Assy
33
34
36
37
38
3
15
11
25
13
19
4
13
7
10
41
14
20
18
21
17
12
22
23
5
6
2
16
15
26
27
See
Detail below
26
27
24
37
22
37
Detail of Sensors
mounting to
Rear Y Ball Screw
Bearing Block
21
40
3
3
Illustrated Parts Breakdown
1-75
Vision Frame Assembly 990087 Parts Listing
Key # Part # Description Quantity
2 001489 MOUNTING BLOCK, MOTOR 1
3 1/4-20 X 3/4" SHCS —
4 001503 PLATE, Y DRIVE STABILITY 1
5 1/4-20 X 1/2" FHS —
6 001487 BLOCK, BEARING REAR Y BALL SREW 1
7 1003319 ASSEMBLY, MOTOR, MODIFICATION, VISION Y 1
10 10-32 X 5/8" SHCS —
11 P3372 ASSEMBLY, BEARING SUPPORT KIT 1
12 P3371 ASSEMBLY, BALL SCREW & NUT 1
13 M5 X 20MM SHCS —
14 001501 BLOCK, SUPPORT, FRONT Y BEARING 1
15 1/4" FLAT WASHER —
16 1/4-20 X 7/8" SHCS —
17 001504 BLOCK, BEARING, FRONT Y BALL SCREW 1
18 8-32 X 1/2" SHCS —
19 001490 BLOCK, MOUNTING, VISION Y BALL NUT 1
20 001505 BRACKET, Y POSITION SENSOR 1
21 8-32 X 3/8" SHCS —
22 P2700 PHOTOMICROSENSOR, SLIM, LIGHT ON/DARK ON 3
23 4-40 X 1/4" SHCS —
24 001531 BRACKET, Y PARK SENSOR 1
25 P3373 COUPLING, FLEX MOTOR 1
26 P3374 BEARING, LINEAR 2
27 M3 X 16MM SHCS —
28NS CA-198-6 CABLE, PROXIMITY SENSOR 1
29NS CA-198-7 CABLE, PROXIMITY SENSOR 1
30NS CA-198-8 CABLE, PROXIMITY SENSOR 1
31 990112 GANTRY BRIDGE ASSEMBLY 1
32 M4 X 14MM SHCS —
33 P2888 CARRIER, CABLE, 1.48" WD 1
quantities are of entire assembly
NS not shown
