KV1-0807 Contents 1 Base Section Base ................................................................ 1-1 2 Cover Section T op Co ver ........................................................ 2-1 Base C o v er ..........…
Note
Rank A : The functions of these parts gradually deteriorate with operating time.
Rank B : The machine stops immediately if the functions of these parts are disabled.
Rank C : The machine still operates even if the functions of these parts are disabled,
because there are many parts.
Rank E : The functions of consumable part gradually deteriorate with operating time.
/ : Maintenance is excluded (The screws are also equal, display is omitted)
Level
: Aims to undergo basic maintenance training and have the capability to do
the job.
Level : Yamaha Corp. aims to render exclusive training
Level : Yamaha Corp. Service Engineering
Level column
Make use of these as reference, “
•
•
”, as mentioned in the Level column.
“
” It is based on taking the basic maintenance training, and being able to do
equal work.
“
” Please contact our company service when it is judged that the customer’s
condition difcult.
From the problem that arises from these, we cannot assume responsibility such as
accidents.
NOTE
Rank A : 機能が徐々に失われる可能性のある部品。
Rank B : 機能を失うとマシンの即停止に繋がる部品。
Rank C : 機能を失っても複数あるのでマシンの即停止とはならない部品。
Rank E : 機能が徐々に失われていく消耗部品。
／ :メンテナンス対象外（ネジ類も同等、但し表示省略）
Level : 基礎メンテナンストレーニングを受けた方、又は同等の作業ができる方が対象。
Level : ヤマハの専用トレーニングを受けた方が対象です。
Level : ヤマハのサービスマンが対象です。
Level 欄について
Level 欄に記載されている
“
•
•
”
はご 参 考としてご 活 用ください 。
“
”
は基礎メンテナンストレーニングを受けた方、又は同等の作業ができる方を
基 準 にして おりま す。
“
”
であってもお客 様が 難しいとご判断された時は弊社サービスまでご連絡ください。
これらに起因する不具合、事故等についての責任は負いかねます。
KV1-0807
Contents
1 Base Section
Base ................................................................1-1
2 Cover Section
Top Cover ........................................................2-1
Base Cover ......................................................2-2
3 Feeder Section
Feeder Holder H (20) ......................................3-1
4 Moving-axis Section
X-axis ...............................................................4-1
Y-axis ...............................................................4-2
YT-axis .............................................................4-3
5 Head Section
Head (SF) .......................................................5-1
Head (FNC) ....................................................5-2
Head Combination ..........................................5-3
6 Nozzle Section
Nozzle (ST) .....................................................6-1
Nozzle (FNC)..................................................6-2
7 Conveyor Unit Section
Push-In ............................................................7-1
Push-Up ..........................................................7-2
Locate-pin .......................................................7-3
Stopper ...........................................................7-4
Edge Clamp .....................................................7-5
Fixed Conveyor (1) ..........................................7-6
Fixed Conveyor (2) ..........................................7-7
Moving Conveyor (1) ......................................7-8
Moving Conveyor (2) ......................................7-9
8 Light Section
Front Light .......................................................8-1
9 Control Section
Control ............................................................9-1
10
Exterior,etc Section
Moniter,etc. ...................................................10-1
1
1
Base
1 Base
KV1-080515
49
61
62
17
7
28
31
5
46
3
7
35
41
36
32
57
59
58
11
12
10
15
38
6
47
30
44
50
35
36
41
8
22
9
24
24
1
25
23
4
40
16
18
34
53
2
27
14
13
38
43
28
26
21
54
60
42
53
63
33
42
45
OLD
64
64
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 KV1-M1101-02X BASE 1 (2000/11/20) OK /
2 KV1-M1120-01X PLATE 10 1 CONECTOR (1999/11/30) OK /
3 KV1-M1112-01X PLATE 2 1 (2000/2/2) OK /
4 KGA-M1113-00X PLATE 3 1 VALVE (2003/5/19) OK /
5 KV7-M1114-01X PLATE 4 1 (2007/12/3) OK /
6 KV7-M1115-00X PLATE 5 1 AIR /
7 KM0-M1141-00X MANUFOLD 2 /
8 KV7-M1116-01X PLATE 6 1 /
9 KG7-M1342-01X BRACKET,F/D 1 /
10 KG2-M8501-00X AIR FILTER 1 /
11 KG2-M8502-00X MIST FILTER 1 /
12 KG2-M8503-00X MODULE ADAPTER 1 /
13 KG2-M8504-01X REGULATOR 1 (2005/6/17) OK /
14 KG2-M8512-00X JOINT 1 /
15 KHN-M8599-00X JOINT,ELBOW 1/2 1 (2007/5/25) OK /
16 KM0-M8582-00X VALVE 1 C
17 KG7-M8596-00X PRESSURE GAUGE 1 R300-03 /
18 KV7-M1118-00X PLATE 8 1 /
21 KV7-M1125-00X PLATE CLAMP 1 /
22 KV1-M1128-00X BRACKET SPEED CONT. 1 /
23 KM0-M1142-00X CASTER 6 Option /
24-1 KM0-M1151-01X PLATE,SIDE 1 1 /
24-2 KM0-M1151-02X PLATE,SIDE 1 1 (2007/6/6) Set /
25 KM0-M1152-01X PLATE SIDE 2 1 /
26 KM0-M1153-01X PLATE SIDE 3 1 /
27 KM0-M1154-01X PLATE BOTOM 1 2 /
28 $SL12-04 JOINT 3 /
30 $TL4-02 JOINT 1 /
31 $UEDW10-8 JOINT 1 /
32 $USD10-8 JOINT 1 /
33 $SL8-01 JOINT 1 /
34 $KM-11 MUFFLER 1 /
35 $TSS4-01 JOINT 12 /
36 $TSH8-01 JOINT 2 /
38 $SL12-03 JOINT 2 /
39 KM5-M4184-00X COVER NOISE FILTER 1 /
40 KV7-M1180-01X LEVELING BOLT ASSY 6 (2000/2/4) OK /
41 K40-M8598-00X PLUG 1 2 /
42-1 90563-03J100 SPACER BOLT 28 (2001/9/1) OK /
42-2 90563-03J100 SPACER BOLT 10 (2007/12/3) NG /
43 KH1-M8501-00X EXHAUST VALVE 1 /
44 $KM-23 MUFFLER 1 /
45 90563-03J200 SPACER BOLT 4 (2001/9/4) OK /
46 KV7-M1161-00X PLATE 11 1 TRANS /
47 KV1-M1113-00X PLATE 3-1 1 REG /
49 KGS-M1153-50X PLATE,SIDE 3 1 (2005/11/17) OK /
50 KV7-M111A-00X BRACKET,GAUGE 1 /
53 KV1-M226C-00X PLATE 2 /
54 KV1-M1116-00X PLATE 6 1 /
57 $UED8-4 JOINT 1 /
58 $UP8 JOINT 3 /
59 $UP4 JOINT 2 /
60 KM5-M8531-00X ACCUMLATAOR 1 /
61 KG2-M8502-40X MIST FILTER 1 CRK557 E
62 KG2-M8501-40X AIR FILTER 1 CRK555 E
63 KG2-M8582-40X VALVE 1 SPARE C
64 KV7-M1325-01X BRACKT 5 2 /
