yv100xt_je - 第5页
1 2 T op Cover KV1-090901 2 Cover 31 21 9 28 22 28 22 20 3 30 28 28 30 1 1 22 26 29 1 1 23 25 1 1 10 27 19 9 22 16 20 25 34 23 14 31 32 2 33 31 32 6 21 31 32 23 7 15 10 5 1 25 5 29 8 10 13 10 23 12 25 17 19 30 16 25 4 21…
1
1
Base
1 Base
KV1-080515
49
61
62
17
7
28
31
5
46
3
7
35
41
36
32
57
59
58
11
12
10
15
38
6
47
30
44
50
35
36
41
8
22
9
24
24
1
25
23
4
40
16
18
34
53
2
27
14
13
38
43
28
26
21
54
60
42
53
63
33
42
45
OLD
64
64
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 KV1-M1101-02X BASE 1 (2000/11/20) OK /
2 KV1-M1120-01X PLATE 10 1 CONECTOR (1999/11/30) OK /
3 KV1-M1112-01X PLATE 2 1 (2000/2/2) OK /
4 KGA-M1113-00X PLATE 3 1 VALVE (2003/5/19) OK /
5 KV7-M1114-01X PLATE 4 1 (2007/12/3) OK /
6 KV7-M1115-00X PLATE 5 1 AIR /
7 KM0-M1141-00X MANUFOLD 2 /
8 KV7-M1116-01X PLATE 6 1 /
9 KG7-M1342-01X BRACKET,F/D 1 /
10 KG2-M8501-00X AIR FILTER 1 /
11 KG2-M8502-00X MIST FILTER 1 /
12 KG2-M8503-00X MODULE ADAPTER 1 /
13 KG2-M8504-01X REGULATOR 1 (2005/6/17) OK /
14 KG2-M8512-00X JOINT 1 /
15 KHN-M8599-00X JOINT,ELBOW 1/2 1 (2007/5/25) OK /
16 KM0-M8582-00X VALVE 1 C
17 KG7-M8596-00X PRESSURE GAUGE 1 R300-03 /
18 KV7-M1118-00X PLATE 8 1 /
21 KV7-M1125-00X PLATE CLAMP 1 /
22 KV1-M1128-00X BRACKET SPEED CONT. 1 /
23 KM0-M1142-00X CASTER 6 Option /
24-1 KM0-M1151-01X PLATE,SIDE 1 1 /
24-2 KM0-M1151-02X PLATE,SIDE 1 1 (2007/6/6) Set /
25 KM0-M1152-01X PLATE SIDE 2 1 /
26 KM0-M1153-01X PLATE SIDE 3 1 /
27 KM0-M1154-01X PLATE BOTOM 1 2 /
28 $SL12-04 JOINT 3 /
30 $TL4-02 JOINT 1 /
31 $UEDW10-8 JOINT 1 /
32 $USD10-8 JOINT 1 /
33 $SL8-01 JOINT 1 /
34 $KM-11 MUFFLER 1 /
35 $TSS4-01 JOINT 12 /
36 $TSH8-01 JOINT 2 /
38 $SL12-03 JOINT 2 /
39 KM5-M4184-00X COVER NOISE FILTER 1 /
40 KV7-M1180-01X LEVELING BOLT ASSY 6 (2000/2/4) OK /
41 K40-M8598-00X PLUG 1 2 /
42-1 90563-03J100 SPACER BOLT 28 (2001/9/1) OK /
42-2 90563-03J100 SPACER BOLT 10 (2007/12/3) NG /
43 KH1-M8501-00X EXHAUST VALVE 1 /
44 $KM-23 MUFFLER 1 /
45 90563-03J200 SPACER BOLT 4 (2001/9/4) OK /
46 KV7-M1161-00X PLATE 11 1 TRANS /
47 KV1-M1113-00X PLATE 3-1 1 REG /
49 KGS-M1153-50X PLATE,SIDE 3 1 (2005/11/17) OK /
50 KV7-M111A-00X BRACKET,GAUGE 1 /
53 KV1-M226C-00X PLATE 2 /
54 KV1-M1116-00X PLATE 6 1 /
57 $UED8-4 JOINT 1 /
58 $UP8 JOINT 3 /
59 $UP4 JOINT 2 /
60 KM5-M8531-00X ACCUMLATAOR 1 /
61 KG2-M8502-40X MIST FILTER 1 CRK557 E
62 KG2-M8501-40X AIR FILTER 1 CRK555 E
63 KG2-M8582-40X VALVE 1 SPARE C
64 KV7-M1325-01X BRACKT 5 2 /
1
2
Top Cover
KV1-090901
2 Cover
31
21
9
28
22
28
22
20
3
30
28
28
30
11
22
26
29
11
23
25
11
10
27
19
9
22
16
20
25
34
23
14
31
32
2
33
31
32
6
21
31
32
23
7
15
10
5
1
25
5
29
8
10
13
10
23
12
25
17
19
30
16
25
4
21
20
18
32
18
21
30
35
25
20
17
25
11
24
24
25
36
37
OLD
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 KV7-M1301-A0X COVER 1 ASSY 1 /
2 KV7-M1302-A0X COVER 2 ASSY 1 /
3 KV7-M1303-A0X COVER 3 ASSY 1 /
4 KV7-M1304-A0X COVER 4 ASSY 1 /
5 KV1-M1305-00X COVER 5 2 /
6 KV7-M1306-A1X COVER 6 ASSY 1 (2000/10/2) OK /
7 KV7-M1307-A0X COVER 7 ASSY 1 /
8 KV7-M1308-A0X COVER 8 ASSY 1 /
9 KV7-M1309-01X COVER,9 2 (2000/10/2) OK /
10 KM0-M1322-00X PLATE PLUG 4 /
11 KM0-M1331-01X BRACKET ,GAS DAMPER 4 /
12 KM8-M1338-01X BRACKET MAIN SWITCH 1 /
13 KV7-M1336-00X BKT CORNER L,BACK 1 /
14 KV7-M1337-00X BKT CORNER L,FRONT 1 /
15 KV7-M1339-00X BKT CORNER R,BACK 1 /
16 KV7-M1340-01X BRACKET 1,COVER 9 2 (2000/10/2) OK /
17 KV7-M1341-02X BRACKET 2,COVER 9 2 (2001/3/28) OK /
18 KV7-M1342-00X BRACKET 3,COVER 9 2 /
19 KV7-M1343-01X BRACKET 4,COVER 9 2 (2000/10/20) OK /
20 KV7-M1349-00X PLATE 2 NUT 4 /
21 K46-M1374-12X HINGE 2 4 (2013/2/13) OK /
22 KH2-M1324-00X GRIP 4 /
23 KL3-M1348-10X GAS SPRING 4 A
24-1 KH5-M13B1-10X BRACKET KEYBOARD 1 /
24-2 KGA-M13B1-00X BRACKET,KEYBOARD 1 (2002/6/11) NG /
25 KM0-M1346-00X SHOULDER,BOLT 8 /
26 KL0-M1318-00X COVER 18 1 /
27 KH1-M13A9-00X BUSH 1 /
28 K93-M1392-00X SPACER 4 TM-180-303 /
29 KV7-M1329-00X COVER 29 2 /
30 KM0-M1335-00X BKT 1 GATE COVER 4 /
31 KM0-M1332-01X BRACKET MAGNET 4 (2001/9/18) OK /
32 KV5-M1130-00X CATCH MG. 4 (2001/9/18) OK /
33 KW7-M13D7-01X SEAL 2 1 YAMAHA (2004/7/28) OK /
34 KV1-M13D6-01X SEAL 1 1 YV100XT (2004/7/26) OK /
35 KV7-M1350-00X CAP,PATLIGHT 1 /
36 KL3-M1381-02X PLATE 1 KEY BOARD 1 (2001/3/28) OK /
37 KL3-M1382-01X PLATE 2 KEY BOARD 1 (2001/3/28) OK /
2
2
Base Cover
Cover
KV1-0801
8
8
8
8
9
8
13
8
8
8
14
16
14
9
14
8
8
15
14
11
14
13
10
11
5
6
6
18
7
3
12
11
9
2
9
11
14
9
4
8
16
10
8
10
11
9
11
1
17
6
6
7
4
1
OLD
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1-1 KV7-M1310-02X COVER 10 1 (1999/11/30) NG /
1-2 KGA-M1310-00X COVER 10 1 (2005/6/2) OK /
2 KV7-M1311-00X COVER 11 1 /
3-1 KV7-M1313-00X COVER 13 1 /
3-2
KV7-M1313-00X COVER 13 1 S.T.D (2004/4/1) OK /
KV7-M1313-10X COVER 13 1 with Power Indicator (2004/4/1) NG /
4 KV7-M1314-00X COVER,14 1 (1999/11/30) OK /
5 KV7-M1315-00X COVER 15 1 /
6 KV7-M1317-01X COVER 17 4 /
7 KV7-M1325-01X BRACKET 5 2 /
8 KG2-M1370-00X HINGE ASSY 12 /
9 K44-M1354-00X MG.CATCH 6 TL-152-2 /
10 KV7-M1326-00X BRACKET 1-1 3 /
11 KV7-M1370-00X BRACKET MAGNET 6 /
12 KV7-M1327-00X BRACKET 1-2 1 /
13 KV7-M1328-00X BRACKET 2 2 /
14 KV7-M1347-00X PLATE BRACKET 6 /
15 KJ0-M4187-00X FAN GUARD 2 /
16 KGS-M1371-00X BRACKET,FIX 2 (2006/2/16) OK /
17 KV7-M1372-00X HANDLE 1 /
18 KV7-M1312-00X COVER,12 1 /
