QP-351E-MM-03 - 第107页
QP-351E-MM P ARTS LIST 2 1 - 7 2 1 . 2 . P F U - 3 E ( D B V H ) 2 1 . 2 . P F U - 3 E ( D B V H ) ﾀ ﾃ x 1 7 3 . 2 0 5 R e f . 3 1 - 1 R e f . 3 1 - 1 R e f . 3 1 - 1 R e f . 3 3 - 7 2 0 8 1 7 6 1 6 5 1 7 5 1 6 1 1 7 5 1…
21.1.PFU-3E(DBVH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
113 N1092A 4
NUT, HEX
ﾅｯﾄ 六角
M10 OT
114 DBUF0230 3 GUIDE, HOLDER ｶﾞｲﾄﾞ 受け FE
115 H5299A 6 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE
116 W1012A 6
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
117 DBVH0270 2 COVER, BLIND 蓋盲 FE
118 N1080A 4
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7 FE
119 W1022A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
120 DBVH0500 1 NAMEPLATE, CAUTION 銘板 注意 French PL
121 DBVH0550 1 COVER, ACRYLIC ｶﾊﾞｰ ｱｸﾘﾙ PL
122 K5172Z 2
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M6X10L FE
123 DBVH0520 2 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ AL
124 H5274A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L FE
125 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
126 DBVH0530 4 BKT, MANIFOLD BKT ﾏﾆﾎｰﾙﾄﾞ FE
127 DBVH0540 2 NAMEPLATE 銘板 PL
128 DBVH0560 1 SEAL ｼｰﾙ PL
注1.ｴｱｰ供給(ｵﾌﾟｼｮﾝ)の場合は必要ありません。
Note.1:Not required during the use of the optional Air supply.
QP-351E-MM PARTS LIST
21 - 6 21.1.PFU-3E(DBVH)
QP-351E-MM PARTS LIST
21 - 7
21.2.PFU-3E(DBVH)
21.2.PFU-3E(DBVH)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
1
36
37
75
37
75
42
74
28
59
44
45
43
20
36
42
9
8
53
52
73
56
54
55
51
50
51
50
7
6
24
23
32
31
35
34
11
12
49
22
33
33
33
30
30
30
29
44
45
43
1
46
2
3
38
20
47
48
26
27
57
25
38
20
38
13
18
38
17
39
41
40
38
20
77
78
38
20
16
2
3
48
47
46
14
38
15
77
78
20
38
16
20
38
20
38
10
5
60
58
3
45
64
62
3
45
63
67
65
61
68
66
3
45
72
71
69
70
3
45
H=950mmH=912mm H=930mm H=962mm
残テ−プカッタ−（オプション）
Waste tape cutter(Option)
76
21
X11.5
21.2.PFU-3E(DBVH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DBVH0020 2 BKT, ROLLER BKT ﾛｰﾗ H=900mm FE
2 H5322A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X15L FE
3 W1024A 8
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
5 DBVH0033 1 COVER ｶﾊﾞｰ FE
6 H5321A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X12L FE
7 W1024A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
8 H5323A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X18L FE
9 W1013A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
10 DBVH0040 1 BOX, DUST BOX ﾀﾞｽﾄ OT
11 DBVH0050 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ FE
12 DBVH0060 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ FE
13 DBVH0070 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ FE
14 DBVH0080 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ FE
15 DBVH0090 1 LEVER, LINK ﾚﾊﾞｰ ﾘﾝｸ FE
16 DBVH0100 2 LEVER, LINK ﾚﾊﾞｰ ﾘﾝｸ FE
17 DBVH0111 1 JACK ｼﾞｬｯｷ OT
18 DBVH0120 1 PIN ﾋﾟﾝ FE
20 W1091A 8 WASHER ﾜｯｼｬ WSSB40-20-3 FE
21 DBWM1220 1 SEAL ｼｰﾙ PL
22 DBVH0160 1 STOPPER ｽﾄｯﾊﾟ FE
23 H5299A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
24 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
25 DBVH0350 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ FE
26 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
27 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
28 DBVH0410 1 SEAL ｼｰﾙ English PL
29 DBVH0420 1 NAMEPLATE 銘板 OT
30 DBUF0240 3 GUIDE ｶﾞｲﾄﾞ PL
31 H5298A 12
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
32 W1023A 12
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
33 DBUF0250 3 GUIDE ｶﾞｲﾄﾞ PL
34 H5298A 12
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
35 W1023A 12
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
36 KPA0890 2 SEAL ｼｰﾙ PL
37 BHUF0650 2 NAMEPLATE, CAUTION 銘板 注意 English PL
38 S1038A 10
CIR-CLIP
ｻｰｸﾘｯﾌﾟ STW20 OT
39 N4026A 1
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M4X4L FE
QP-351E-MM PARTS LIST
21 - 8 21.2.PFU-3E(DBVH)
