33.MTU-9E シャトル(DBTN) 33.MTU-9E Suttle(DBTN) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 81 H5300A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE 82 W1023A 2 WASHER, LOCK ﾜ…
33.MTU-9E シャトル(DBTN)
33.MTU-9E Suttle(DBTN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
44 DBTN1130 1 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ FE
45 H5170A 2
BOLT, HEX
ﾎﾞﾙﾄ 六角
M4X12L FE
46 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
47 DBTN1160 1 COVER ｶﾊﾞｰ FE
48 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
49 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
50 DBTN1170 1 BKT BKT FE
51 H5301A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X18L FE
52 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
53 DBTN1180 3 BKT, RAIL BKT ﾚｰﾙ FE
54 H5300A 6 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
55 W1023A 6
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
56 W1044A 6 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
57 DBTN1190 1 RAIL ﾚｰﾙ FE
58 H5290A 3
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L FE
59 W1022A 3
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
60 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
61 W1010A 2
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L FE
62 DBTN1200 1 RAIL ﾚｰﾙ FE
63 H5290A 3
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L FE
64 W1022A 3
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
65 DBTN1210 2 BKT, STOPPER BKT ｽﾄｯﾊﾟ FE
66 DBTN1220 2 STOPPER ｽﾄｯﾊﾟ PL
67 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
68 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
69 W1040A 2 WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7(1W-3) FE
70 DBTN1230 1 BKT BKT FE
71 H5274A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L FE
72 W1010A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L FE
73 DBTN1330 1 BKT, SENSOR BKT ｾﾝｻ FE
74 H5289A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L FE
75 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
76 W1043A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
77 DBTN1350 1 PANEL, CONNECTOR ﾊﾟﾈﾙ ｺﾈｸﾀ FE
78 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
79 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
80 DBTN1361 1 BKT, SENSOR BKT ｾﾝｻ FE
QP-351E-MM PARTS LIST
33 - 3
33.MTU-9E シャトル(DBTN)
33.MTU-9E Suttle(DBTN)
33.MTU-9E シャトル(DBTN)
33.MTU-9E Suttle(DBTN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
81 H5300A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
82 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
83 W1044A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
84 DBTN1370 1 BKT, SENSOR BKT ｾﾝｻ Option FE
85 H5299A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
86 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
87 W1044A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
88 DBTN1380 1 COVER ｶﾊﾞｰ FE
89 K5208A 2 SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L FE
90 DBTN1431 1 BKT BKT FE
91 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
92 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
93 DBTN1440 1 COVER, WIRING ｶﾊﾞｰ 配線 FE
94 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
95 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
96 DBTN1450 1 COVER, WIRING ｶﾊﾞｰ 配線 FE
97 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
98 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
100 H5299A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
101 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
102 K51711 1 SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M5X6L FE
103 DBTN1700 2 PULLEY ﾌﾟｰﾘ OT
104 BHTC5030 1 FIXTURE, CLAMP 金具 ｸﾗﾝﾌﾟ OT
105 H5266A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X6L FE
106 W1020A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M FE
107 BHTC5090 1 PULLEY, MOTOR ﾌﾟｰﾘ ﾓｰﾀ OT
108 N4020T 2 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止ﾒ M3X5Lﾋﾗｻｷ FE
109 GVC0141 1 COLLAR ｶﾗｰ FE
110 DBTN1740 4 COLLAR ｶﾗｰ FE
111 PPT0460 2 COLLAR ｶﾗｰ FE
112 SAM6580 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ OT
113 H5288A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L FE
114 W1011A 2
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
115 S4045B 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX772 OT
116 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
117 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
118 H4573A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 1422-3GT-9 OT
QP-351E-MM PARTS LIST
33 - 4
33.MTU-9E シャトル(DBTN)
33.MTU-9E Suttle(DBTN)
33.MTU-9E シャトル(DBTN)
33.MTU-9E Suttle(DBTN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
119 K2107H 2 KEY ｷｰ KEDZ10-20 OT
120 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
121 H5123S 2 BOLT, CLAMP ﾎﾞﾙﾄ ｸﾗﾝﾌﾟ HRSM10-50 FE
124 H42323 8 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ FLAWBC5-10-22A OT
125 N1069T 4 NUT U ﾅｯﾄ U M5 P=0.3 OT
126 H4440A 2
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ OT
127 EM42301 2 WASHER, FLAT ﾜｯｼｬ 平 FE
128 S4068A 1 SENSOR, AREA ｾﾝｻ ｴﾘｱ F3S-A321 OT
129 H5329A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X35L FE
130 W1031A 2
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
131 ADBTN8240 1 ARM ｱｰﾑ OT
132 DBTN1461 1 ARM ｱｰﾑ FE
133 H5278A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X15L FE
134 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
135 DBTN1250 1 DOG ﾄﾞｯｸﾞ FE
136 H5286A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L FE
137 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
138 DBTN1580 1 HOOK ﾌｯｸ FE
139 H5287A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
140 W1022A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
141 DBTN1480 1 PLATE ﾌﾟﾚｰﾄ FE
142 DBTN1610 2 WASHER ﾜｯｼｬ FE
143 DBTN1600 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
144 DBTN1590 2 PIN, CLAMP ﾋﾟﾝ ｸﾗﾝﾌﾟ OT
145 N1076A 2
NUT, HEX
ﾅｯﾄ 六角
M3 P=0.5 OT
146 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
147 W1040A 2 WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7(1W-3) FE
148 DBTN1570 2 ROLLER ﾛｰﾗ PL
149 DBTN1560 2 PIN, ROLLER ﾋﾟﾝ ﾛｰﾗ FE
150 H5493T 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ STBB4-30 FE
151 N1080A 2
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7 OT
152 S1031A 4
CIR-CLIP
ｻｰｸﾘｯﾌﾟ STW10 OT
153 H4287N 2
BEARING, SLIDE
ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ LM-05L OT
154 DBTN1710 2 PULLEY ﾌﾟｰﾘ FE
155 DBTN1530 1 BKT, SENSOR BKT ｾﾝｻ FE
156 H5288A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L FE
157 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
QP-351E-MM PARTS LIST
33 - 5
