39.2.グルーヘッド(オプション)(DBHG) 39.2.Glue head(Option)(DBHG) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 38 W1021A 2 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE 39 B6982DBHG3630 1…
39.2.グルーヘッド(オプション)(DBHG)
39.2.Glue head(Option)(DBHG)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 B6982DBHG2022 1 SLIDE, Z-AXIS ｽﾗｲﾄﾞ Z軸 AL
2 H5273A 12
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5 FE
3 W1010A 12
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L FE
4 B6982DBHG5730 1 BKT BKT AL
5 H5277A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X12 FE
6 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
7 1 PLUNGER ﾌﾟﾗﾝｼﾞｬ LBSU4 OT
8 N4018A 1
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X3 FE
9 B6982DBHG5631 1 HOLDER 受け FE
10 H5282A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X30 FE
11 W1021A 1
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
12 B6982DBHG2680 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ OT
13 H5275A 11
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8 FE
14 B6982DBHG2690 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ OT
15 H5275A 5
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8 FE
16 B6982DBHG2601 1 DOG ﾄﾞｯｸﾞ FE
17 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8 FE
18 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
19 W1042A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
20 S31163 1 SW, PROXIMITY SW 近接 FL7T-P5B6-914 OT
21 B6982DBHG3591 1 BKT, SENSOR BKT ｾﾝｻ FE
22 H5265A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X5 FE
23 W1020A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M FE
24 S3128A 1
SW, PHOTOELECTRIC
SW 光電
EZ-18T OT
25 K5256A 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M3X8 FE
26 B6982DBHG1441 1 BKT, MOTOR BKT ﾓｰﾀ AL
27 H5276A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10 FE
28 SAM6600 1 MOTOR ﾓｰﾀ OT
29 DBPH0070 1 GEAR ｷﾞﾔ FE
30 N10735 1 NUT, HEX ﾅｯﾄ 六角 M2 OT
31 B6982DBHG1181 1 SHAFT ｼｬﾌﾄ FE
32 H4441A 2
BEARING, MINIATURE
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-840ZZ OT
33 B6982DBHG1470 1 GEAR, INTERMEDIATE ｷﾞﾔ 中間 FE
34 B6982DBHG1490 1 COLLAR ｶﾗｰ FE
35 B6982DBHG1480 1 COLLAR ｶﾗｰ FE
36 B6982DBHG5600 1 BKT, MOTOR BKT ﾓｰﾀ AL
37 H5280A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X20 FE
QP-351E-MM PARTS LIST
39 - 10
39.2.グルーヘッド(オプション)(DBHG)
39.2.Glue head(Option)(DBHG)
39.2.グルーヘッド(オプション)(DBHG)
39.2.Glue head(Option)(DBHG)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
38 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
39 B6982DBHG3630 1 STOPPER ｽﾄｯﾊﾟ FE
40 B6982DBHG5641 1 HOLDER 受け FE
41 H5275A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8 FE
42 W1021A 1
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
43 Y9420DBHG1621 1 MOTOR ﾓｰﾀ OT
44 B6982DBHG1200 1 GEAR ｷﾞﾔ FE
45 N4019A 1
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X4 FE
47 B6982DBHG5300 1 SPRING ｽﾌﾟﾘﾝｸﾞ FE
48 B6982DBHG2050 1 SHAFT ｼｬﾌﾄ FE
49 B6982DBHG5260 1 SPRING ｽﾌﾟﾘﾝｸﾞ FE
50 B6982DBHG2671 1 BLOCK ﾌﾞﾛｯｸ AL
51 H5273T 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X4 FE
52 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
53 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8 FE
54 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
55 B6982DBHG3830 1 GUIDE ｶﾞｲﾄﾞ PL
56 H5276A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10 FE
57 W1021A 1
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
58 B6982DBHG2120 1 SHAFT ｼｬﾌﾄ FE
59 N1082A 1
NUT, HEX
ﾅｯﾄ 六角
M5 OT
60 W1023A 1 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
61 B6982DBHG1310 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ OT
62 H5276A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10 FE
63 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
64 B6982DBHG1891 1 STOPPER ｽﾄｯﾊﾟ PL
65 B6982DBHG1870 1 STOPPER ｽﾄｯﾊﾟ PL
66 DBPH0240 1 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ FE
67 B6982DBHG1012 1 RETAINER, BEARING 押え ﾍﾞｱﾘﾝｸﾞ FE
69 1
BEARING
ﾍﾞｱﾘﾝｸﾞ SEA12 7CE1 DUL OT
70 B6982DBHG1052 1 COLLAR, BEARING ｶﾗｰ ﾍﾞｱﾘﾝｸﾞ FE
71 B6982DBHG1061 1 COLLAR, BEARING ｶﾗｰ ﾍﾞｱﾘﾝｸﾞ FE
72 B6982DBHG1080 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ FE
73 N4016A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M2X2 FE
74 B6982DBHG1046 1 GEAR ｷﾞﾔ FE
76 B6982DBHG3160 1 PIN ﾋﾟﾝ FE
77 B6982DBHG7331 1 NOZZLE ﾉｽﾞﾙ FE
QP-351E-MM PARTS LIST
39 - 11
39.2.グルーヘッド(オプション)(DBHG)
39.2.Glue head(Option)(DBHG)
39.2.グルーヘッド(オプション)(DBHG)
39.2.Glue head(Option)(DBHG)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
78 B6982DBHG5400 1 BLOCK ﾌﾞﾛｯｸ AL
79 H5290A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15 FE
80 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
81 A4126A 1 ELBOW ｴﾙﾎﾞ KJW06-M5 OT
82 1 SENSOR ｾﾝｻ E52-CA3AE-2 OT
83 K5268C 1 BLOCK, CLAMP 駒 ｸﾗﾝﾌﾟ SEPN-4 OT
84 N4021A 1
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X6 FE
85 B6982DBHG5421 1 FLANGE ﾌﾗﾝｼﾞ AL
86 3 SCREW, COUNTERSUNK 小ﾈｼﾞ 皿(0番1種) M2X2.5 FE
87 B6982DBHG5410 1 COVER 蓋 AL
88 2 SCREW, COUNTERSUNK 小ﾈｼﾞ 皿(0番1種) M2X2.5 FE
89 B6982DBHG3381 1 CAP ｷｬｯﾌﾟ AL
90 B6982DBHG7271 1 PLATE ﾌﾟﾚｰﾄ FE
91 H5276A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10 FE
92 1 BEARING ﾍﾞｱﾘﾝｸﾞ RB2508UUCC0P5 OT
93 B6982DBHG1021 1 NUT, LOCK ﾅｯﾄ ﾛｯｸ FE
94 Y9420DBHG1091 4 BLOCK, CLAMP 駒 ｸﾗﾝﾌﾟ CO
95 N4016A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M2X2 FE
96 B6982DBHG5523 1 GEAR ｷﾞﾔ FE
97 B6982DBHG5850 2 PIN DIAMOND-SHAPED ﾋﾟﾝ ﾀﾞｲﾔ OT
98 B6982DBHG3750 1 PIN, PARALLEL ﾋﾟﾝ 平行 FE
101 1 O RING Oﾘﾝｸﾞ S5，ﾌｯ素ｺﾞﾑ ﾃﾌﾛﾝｺｰﾃｨﾝｸﾞ OT
102 B6982DBHG7141 1 HOLDER ﾎﾙﾀﾞ OT
103 1 O RING Oﾘﾝｸﾞ S6，ﾌｯ素ｺﾞﾑ ﾃﾌﾛﾝｺｰﾃｨﾝｸﾞ OT
104 B6982ADBHG8031 1 HOLDER ROTATION ﾎﾙﾀﾞ ｶｲﾃﾝ OT
105 1 O RING Oﾘﾝｸﾞ S10，ﾌｯ素ｺﾞﾑ ﾃﾌﾛﾝｺｰﾃｨﾝｸﾞ OT
107 BTRG0750 1 SYRINGE ｼﾘﾝｼﾞ PL
108 ANRG1202 1 FLOAT ﾌﾛｰﾄ OT
109 1 O RING Oﾘﾝｸﾞ S22，ﾌｯ素ｺﾞﾑ ﾃﾌﾛﾝｺｰﾃｨﾝｸﾞ YT
110 B6982DBHG5382 1 ADAPTER ｱﾀﾞﾌﾟﾀ AL
111 B6982DBHG3820 1 ADAPTER ｱﾀﾞﾌﾟﾀ PL
112 H5265A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M2X5 FE
113 W1020A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M FE
114 H2039M 1
PIN, SPRING
ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 1.5゜X6L OT
115 1 PLUG ﾌﾟﾗｸﾞ 1TPM OT
116 1
SOCKET
ｿｹｯﾄ 1TSM OT
117 1 ELBOW ｴﾙﾎﾞ 4616SEU-1/8 OT
QP-351E-MM PARTS LIST
39 - 12
39.2.グルーヘッド(オプション)(DBHG)
39.2.Glue head(Option)(DBHG)
