QP-351E-MM P ARTS LIST 4 2 - 1 4 2 . エアー配管図( グルーヘッド) ( オプション) ( D B W I ) 4 2 . P n e u m a t i c c i r c u i t d i a g r a m ( G l u e h e a d ) ( O p t i o n ) ( D B W I ) 4 2 . エアー配管図( グルーヘッド) ( オプション) ( D B W I ) …
41.エアー機器 2(グルーヘッド)(オプション)(DBWI)
41.Air device 2(Glue head)(Option)(DBWI)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 Y9420DBWI0170 1 BKT BKT FE
2 Y9420DBWI0030 1 BKT BKT FE
3 B6982DBWI0030 1 COVER ｶﾊﾞｰ FE
4 Y9420DBWI0050 1 PLATE ﾌﾟﾚｰﾄ OT
5 Y9420DBWI0060 1 HOLDER ﾎﾙﾀﾞ AL
6 B6982DBWI0040 1 COVER ｶﾊﾞｰ FE
7 Y9420DBWI0160 1 BKT BKT FE
8 BTPZ0120 2 HOLDER ﾎﾙﾀﾞ OT
9 1 COOLER ｸｰﾗ MODEL185-65SV OT
10 1 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ CVR02A OT
11 1 HEATER ﾋｰﾀ SAH-2PH 200V180W OT
12 Y3079T 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L08-02S OT
13 1 UNION ﾕﾆｵﾝ KQ2N10-03S OT
14 1 UNION ﾕﾆｵﾝ KQ2H10-00 OT
15 1 UNION ﾕﾆｵﾝ KQ2F10-02 OT
16 1 UNION ﾕﾆｵﾝ KQ2Y08-02S OT
17 1 UNION ﾕﾆｵﾝ KQ2N08-99 OT
18 1 UNION ﾕﾆｵﾝ KQ2LF08-02 OT
19 A4021A 1
ELBOW
ｴﾙﾎﾞ SLA02-000J OT
20 1 ELBOW ｴﾙﾎﾞ KL8-02-NR OT
22 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8 FE
23 H5282A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X30 FE
24 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8 FE
25 H5307A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X40 FE
26 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
27 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
28 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
29 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
30 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8 FE
31 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
32 H5285A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X5 FE
33 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
34 W1044A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
QP-351E-MM PARTS LIST
41 - 2
41.エアー機器 2(グルーヘッド)(オプション)(DBWI)
41.Air device 2(Glue head)(Option)(DBWI)
QP-351E-MM PARTS LIST
42 - 1
42.エアー配管図(グルーヘッド)(オプション)(DBWI)
42.Pneumatic circuit diagram(Glue head)(Option)(DBWI)
42.エアー配管図(グルーヘッド)(オプション)(DBWI)
42.Pneumatic circuit diagram(Glue head)(Option)(DBWI)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
11SOL2A
11SOL1A
Nozzle A
Nozzle B
11SOL1B
11SOL2B
Z軸落下防止
Z-axis drop
prevention
装着ヘッド関係 (DBPH)
Placing head
X軸ケーブルベア
X-axis flexble track
Y-axis flexble track
Y軸ケーブルベア
4.5Kg/cmセット圧
Set pressure
2
4.5Kg/cm
2
5Kg/cm
2
エアー供給源
Air supply
HG4
HG2
HG1
HG1
(ドレン)
(Drain)
17SOL2
UBS-0850-20-W (PISCO)
Glue head
グル−ヘッド関係(DBHG)
グル−温調機器(DBWI)
Glue temperature control
Glue air device
グル−エア−機器(DBWI)
HG7
HG6
HG4
HG9
HG8
HG7
HG8
HG7
HG6
HG4
HG7
HG6
HG4
HG3
HG5
B2
1/2
B2
φ6
φ6
φ6
φ8
φ6
φ8
φ8
φ8
φ8
φ8
φ8
φ10
φ10
Air温度検知装置
Air thermostat
Air thermostat
φ10
φ8
コルダー圧0.3MPa
Cooler pressure 0.3MPa
塗布圧 ***MPa
Glue pressure ***MPa
ヒーター圧0.04MPa
Heater pressure 0.04MPa
3SOL-13SOL-2
φ10
φ8
X
Air温度検知装置 BTPZ0210
BTPZ0210
φ10
φ8
φ8
HG8
φ6
UBS-0640-20-W (PISCO)
x9
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
15
393635
14
33
3231
13
37
17
27
26 25
6
28
5
23
23
24
19
20
1
21
2
3
4
30
22
2129
7
22
8
22 22
10
30
9
22
30
12
11
22
22
8
38
18
22
34
40
24
42
41
42.エアー配管図(グルーヘッド)(オプション)(DBWI)
42.Pneumatic circuit diagram(Glue head)(Option)(DBWI)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 1 SEPARATOR, MIST ｾﾊﾟﾚｰﾀ ﾐｽﾄ AFD3000-03BC OT
2 1 VALVE, ELEC/AIR PROPORTIO ﾊﾞﾙﾌﾞ ﾃﾞﾝｸｳﾋﾚｲ VY1200-02-N OT
3 S1059A 1
SILENCER
ｻｲﾚﾝｻ AN200-02 OT
4 A1030A 1 PRESSURE GAUGE 圧力計 G36-07-01 OT
5 1 VALVE ﾊﾞﾙﾌﾞ VQZ212-5L-M5 OT
6 1 SILENCER ｻｲﾚﾝｻ INA-25-46 OT
7 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ VXO10030A-2-4 OT
8 2 VALVE ﾊﾞﾙﾌﾞ VX2121-00-5DZ OT
9 H1027A 1
VALVE, PRESSURE REDUCING
ﾊﾞﾙﾌﾞ 減圧
ARP3000-02B OT
10 A1029A 1 PRESSURE GAUGE 圧力計 G36-02-01 OT
11 H1029A 1
VALVE, PRESSURE REDUCING
ﾊﾞﾙﾌﾞ 減圧
AR2000-02B OT
12 A1030T 1
PRESSURE GAUGE
圧力計
G36-10-01 OT
13 K3002Z 1 COOLER ｸｰﾗ ｺﾙﾀﾞｰ185-65SV OT
14 1 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ CVR02A OT
15 1 HEATER ﾋｰﾀ SAH-2PH 200V180W OT
17 1 VALVE ﾊﾞﾙﾌﾞ 4616 SEU-1/8 OT
18 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2VT10-04S OT
19 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L10-03S OT
20 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2Z10-03S OT
21 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L10-02S OT
22 8 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L08-02S OT
23 2 UNION ﾕﾆｵﾝ KQ2H08-00 OT
24 2 UNION ﾕﾆｵﾝ KQ2H06-08 OT
25 Y3049T 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-01S OT
26 Y3079N 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-M5 OT
27 Y3083A 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQ2H06-01S OT
28 1 CAP ｷｬｯﾌﾟ UC6 OT
29 1 NIPPLE ﾆｯﾌﾟﾙ Rni3/8X1/4 OT
30 3 ELBOW ｴﾙﾎﾞ SL-1/8 OT
31 1 UNION ﾕﾆｵﾝ KQ2N10-03S OT
32 Y3068A 1 UNION ﾕﾆｵﾝ KQ2H10-00 OT
33 1 UNION ﾕﾆｵﾝ KQ2F10-02 OT
34 1 UNION ﾕﾆｵﾝ KQ2Y08-02S OT
35 1 UNION ﾕﾆｵﾝ KQ2N08-99 OT
36 1 ELBOW ｴﾙﾎﾞ KQ2LF08-02 OT
37 1 UNION ﾕﾆｵﾝ KJW06-M5 OT
38 A4066H 1 ELBOW ｴﾙﾎﾞ KQ2L10-99 OT
QP-351E-MM PARTS LIST
42 - 2
42.エアー配管図(グルーヘッド)(オプション)(DBWI)
42. Pneumatic circuit diagram(Glue head)(Option)(DBWI)
