QP-351E-MM PARTS LIST
43 - 1
43.1.グルー捨て打ちユニット(オプション)(DBHG)
43.1.Glue check unit(Option)(DBHG)
43.1.グルー捨て打ちユニット(オプション)(DBHG)
43.1.Glue check unit(Option)(DBHG)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
A
E
E
B
B
F
C
C
D
D
A
F
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
63
62
64
58
59
60
61
57
68
68
66
67
66
67
65
19
19
18
17
20
21
22
22
22
22
12
11
10
13
14
15
16
2
2
8
9
7
4
5
6
1
3
96
96
93
23
24
25
26
27
28
69
70
71
72
77
77
73
74
75
76
76
84
31
33
34
97
97
98
99
98
99
40
41
42
39
43
44
50
54
55
56
53
52
45
51
48
49
46
47
78
79
79
83
82
81
80
101
100
102
102
103
104
85
86
86
87
90
91
88
89
94
95
105
18%
43.1.グルー捨て打ちユニット(オプション)(DBHG)
43.1.Glue check unit(Option)(DBHG)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 B6982DBHG6013 1 PLATE ﾌﾟﾚｰﾄ AL
2 K5255T 8 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M3X6 FE
3 K5257A 4
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M4X8 FE
4 B6982DBHG6021 1 GUIDE ｶﾞｲﾄﾞ AL
5 H5299A 3
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X12 FE
6 W1012A 3
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-5-L FE
7 B6982DBHG6050 1 PLATE ﾌﾟﾚｰﾄ FE
8 H5299A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X12 FE
9 W1012A 2
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-5-L FE
10 B6982DBHG6250 1 PLATE ﾌﾟﾚｰﾄ FE
11 K5255H 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M3X5 FE
12 1 HANDLE 取手 THA-239-8 OT
13 H5300A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15 FE
14 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
15 1 MAGNET CATCH ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-98S OT
16 H5264A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M2X3 FE
17 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ SS5YJ3-31-2-M3 OT
18 H5280A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X20 FE
19 2 VALVE，SOL ﾊﾞﾙﾌﾞSOL SYJ3130-5G OT
20 S1058A 1
SILENCER
ｻｲﾚﾝｻ AN120-M5 OT
21 Y3049G 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL04-M5(ｼﾛ) OT
22 A4067A 4
ELBOW
ｴﾙﾎﾞ M-3ALU-4 OT
23 1 EJECTOR ｴｼﾞｪｸﾀ VDBE07P6-06SA OT
24 H5280A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X20 FE
25 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
26 B6982DBHG6140 1 BKT BKT FE
27 H5297A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M5X8 FE
28 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
31 B6982DBHG6350 1 PLATE, LIFTER ﾌﾟﾚｰﾄ ﾘﾌﾀ AL
32 K5257E 4
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M4X10 FE
33 B6982DBHG6070 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ FE
34 4
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M2.5X5 FE
39 1 BKT, SENSOR BKT ｾﾝｻ E39-L120 OT
40 K5255T 2 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M3X6 FE
41 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
42 W1042A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
43 1 SENSOR ｾﾝｻ E3T-FD11 OT
QP-351E-MM PARTS LIST
43 - 2
43.1.グルー捨て打ちユニット(オプション)(DBHG)
43.1.Glue check unit(Option)(DBHG)
43.1.グルー捨て打ちユニット(オプション)(DBHG)
43.1.Glue check unit(Option)(DBHG)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
44 K51727 2 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M2X8 FE
45 B6982DBHG6270 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ AL
46 B6982DBHG6100 1 RETAINER 押え FE
47 K5255T 2 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M3X6 FE
48 B6982DBHG6090 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押ｴ FE
49 H5273A 3
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X5 FE
50 B6982DBHG6290 1 GUIDE ｶﾞｲﾄﾞ FE
51 K5170T 5
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
52 B6982DBHG6110 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ RSH9ZMMUU+295LM OT
53 H5274A 15
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X6 FE
54 B6982DBHG6230 1 PLATE ﾌﾟﾚｰﾄ FE
55 S4045B 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX772 OT
56 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X8 FE
57 B6982DBHG6041 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ AL
58 B6982DBHG6090 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押ｴ FE
59 H5273A 3
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X5 FE
60 B6982DBHG6280 1 GUIDE ｶﾞｲﾄﾞ FE
61 K5170T 5
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
62 B6982DBHG6340 1 TRAY ﾄﾚｲ FE
63 K5170T 2
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
64 K5202A 1
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M3X3 FE
65 1 CYLINDER, RODLESS ｼﾘﾝﾀﾞ ﾛｯﾄﾞﾚｽ CY1R10H-250-Y59A OT
66 H5281A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X25 FE
67 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
68 K5337H 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1201F-M5-04 OT
69 B6982DBHG6320 1 BKT BKT FE
70 H5273A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X5 FE
71 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
72 W1042A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
73 H5274A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X6 FE
74 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
75 B6982DBHG6330 1 MANIFOLD, AIR ﾏﾆﾎｰﾙﾄﾞ ｴｱｰ AL
76 K5255T 4 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M3X6 FE
77 2 PAD, VACUUM ﾊﾟｯﾄ ﾊﾞｷｭｰﾑ VPE8R OT
78 B6982DBHG6300 1 COVER, ACRYLIC ｶﾊﾞｰ ｱｸﾘﾙ PL
79 K5186N 6
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿       
M3X5 FE
80 B6982DBHG6310 1 GUIDE, HOLDER ｶﾞｲﾄﾞ 受け AL
QP-351E-MM PARTS LIST
43 - 3
43.1.グルー捨て打ちユニット(オプション)(DBHG)
43.1.Glue check unit(Option)(DBHG)
