16.1.コンベア(DBPQ) 16.1.Conveyor(DBPQ) 番号図番 & ｺｰﾄﾞ番号個数品名規格備考材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 149 IQC5760 1 COLLAR ｶﾗｰ FE 150 PPT0540 4 STOPPER ｽﾄｯﾊﾟ FE 151 N1082A 4 NUT, HEX ﾅ…

16.1.コンベア(DBPQ)

16.1.Conveyor(DBPQ)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考材質

No. Drg.No. & Code No. QTY Description Rating Remarks Materials

112 W1041A 2 WASHER, FLAT ﾜｯｼｬ平 4M/MX0.8X9(1W-4) FE

113 DBPP0570 1 BKT BKT FE

114 K5359E 2

SCREW, HEX SOCKET COUNTERSUNK

小ﾈｼﾞ六角穴皿 M4X8L FE

115 DBPP0580 1 BKT, SENSOR BKT ｾﾝｻ FE

116 H5289A 2

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M4X12L FE

117 W1022A 2

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 4M/M FE

118 W1041A 2 WASHER, FLAT ﾜｯｼｬ平 1W-4 FE

119 DBPP0590 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE

120 H5299A 2

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X12L FE

121 W1023A 2

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M FE

122 H5275A 2

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M3X8L FE

123 W1021A 2

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 3M/M FE

124 BHPP1080 1 HOLDER ﾎﾙﾀﾞ FE

125 BHPP1150 1 PULLEY ﾌﾟｰﾘ FE

126 H5299A 1

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X12L FE

127 W1023A 1

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M FE

128 BHPP1160 1 SHAFT ｼｬﾌﾄ FE

129 BHPP1210 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ FE

130 N4026A 1

SCREW, HEX SOCKET SET

ﾈｼﾞ六角穴止め

M4X4L FE

131 BHPP1260 1 COLLAR ｶﾗｰ FE

132 BHPP1270 1 SHAFT ｼｬﾌﾄ FE

133 W1024A 1

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 6M/M FE

134 W1045A 1 WASHER, FLAT ﾜｯｼｬ平 4W-6 FE

135 N1086A 1 NUT, HEX ﾅｯﾄ六角 M6 3ｼｭ OT

136 BHPP1290 2 COLLAR ｶﾗｰ FE

137 BHPP1331 2 PLATE ﾌﾟﾚｰﾄ FE

138 K5186W 4

SCREW, HEX SOCKET COUNTERSUNK

小ﾈｼﾞ六角穴皿 M3X8L FE

139 BHPP1341 2 PLATE ﾌﾟﾚｰﾄ FE

140 K5186W 4

SCREW, HEX SOCKET COUNTERSUNK

小ﾈｼﾞ六角穴皿 M3X8L FE

141 BHPP1790 4 PULLEY ASSY ﾌﾟｰﾘ ASSY OT

142 BHPP1800 4 PULLEY ASSY ﾌﾟｰﾘ ASSY OT

143 BHPP1810 1 PULLEY ﾌﾟｰﾘ FE

144 GVC0141 5 COLLAR ｶﾗｰ FE

145 GVC0350 1 COLLAR ｶﾗｰ FE

146 IQC5440 1 RETAINER, BEARING 押えﾍﾞｱﾘﾝｸﾞ FE

147 K5357M 3

SCREW, HEX SOCKET COUNTERSUNK

小ﾈｼﾞ六角穴皿

M3X6L FE

148 IQC5750 1 COLLAR ｶﾗｰ FE

QP-351E-MM PARTS LIST

16 - 6

16.1.コンベア(DBPQ)

16.1.Conveyor(DBPQ)

16.1.コンベア(DBPQ)

16.1.Conveyor(DBPQ)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考材質

No. Drg.No. & Code No. QTY Description Rating Remarks Materials

149 IQC5760 1 COLLAR ｶﾗｰ FE

150 PPT0540 4 STOPPER ｽﾄｯﾊﾟ FE

151 N1082A 4

NUT, HEX

ﾅｯﾄ六角

M5 1ｼｭ OT

152 PPT1381 2 GUIDE ｶﾞｲﾄﾞ FE

153 PPT1391 2 GUIDE ｶﾞｲﾄﾞ FE

154 PPT1531 4 PIN, ECCENTRIC ﾋﾟﾝ偏心 FE

155 H4104A 2

BEARING

ﾍﾞｱﾘﾝｸﾞ A-2520 OT

156 H4445A 2

BEARING, MINIATURE

ﾍﾞｱﾘﾝｸﾞﾐﾆﾁｭｱ LF-1050ZZ OT

157 H4440A 10

BEARING, MINIATURE

ﾍﾞｱﾘﾝｸﾞﾐﾆﾁｭｱ L-1910ZZ OT

158 S1022A 1

CIR-CLIP

ｻｰｸﾘｯﾌﾟ ST-EW-4 OT

159 S1046A 1

CIR-CLIP

ｻｰｸﾘｯﾌﾟ WR19 OT

160 K11384 1

COLLAR

ｶﾗｰ SRW8 OT

161 H2057A 1

PIN, SPRING

ﾋﾟﾝｽﾌﾟﾘﾝｸﾞ 4ﾟX15 OT

162 A1040Z 2 AMPLIFIER ｱﾝﾌﾟ FIRM-04 OT

163 S4052T 2

SENSOR, FIBER

ｾﾝｻﾌｧｲﾊﾞ F9573 OT

164 S3020T 4

SPRING

ｽﾌﾟﾘﾝｸﾞ WF5-30 OT

165 S1003A 1

CIR-CLIP

ｻｰｸﾘｯﾌﾟ RTW19 OT

166 S3034A 1 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 2ｶﾞﾀ OT

167 S1031A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ STW 10 OT

168 S40545 2 SENSOR, FIBER ｾﾝｻﾌｧｲﾊﾞ HPF-S086-A OT

169 A1042Z 2 AMPLIFIER ｱﾝﾌﾟ HPX-H1-019 OT

170 K5169T 4 SCREW, C/R COUNTERSUNK 小ﾈｼﾞ十穴皿 M2X6L FE

171 M5014Z 1 MOTOR, INDUCTION ﾓｰﾀｲﾝﾀﾞｸｼｮﾝ MSM315-401-E1 OT

172 H4009A 1

HEAD, GEAR

ﾍｯﾄﾞｷﾞﾔ 3GN-7.5K OT

173 H53161 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M5X95L FE

174 W1023A 4

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M FE

175 S2126L 1

CYLINDER, AIR

ｼﾘﾝﾀﾞｴｱｰ CXSM10-K6869-35 OT

176 Y3045G 2 UNION, ELBOW ﾕﾆｵﾝｴﾙﾎﾞ TL4-M5M OT

177 T2189M 1 CHAIN ﾁｪｰﾝ RS25 238LINK OT

178 DBPP0540 1 SHAFT, ROTATING ｼｬﾌﾄ回転 FE

179 N1085A 1

NUT, HEX

ﾅｯﾄ六角

M6 P=1.0 OT

180 W1024A 1

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 6M/M FE

181 W1045A 1 WASHER, FLAT ﾜｯｼｬ平 4W-6 FE

182 H2059A 1

PIN, SPRING

ﾋﾟﾝｽﾌﾟﾘﾝｸﾞ 4ﾟX20 OT

183 DBPP0550 1 HANDLE ﾊﾝﾄﾞﾙ AHG50C OT

184 K1038L 1 COUNTER ｶｳﾝﾀ SDP-04HR-4B OT

185 K1135H 1 COLLAR ｶﾗｰ STS-12S OT

QP-351E-MM PARTS LIST

16 - 7

16.1.コンベア(DBPQ)

16.1.Conveyor(DBPQ)

16.1.コンベア(DBPQ)

16.1.Conveyor(DBPQ)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考材質

No. Drg.No. & Code No. QTY Description Rating Remarks Materials

186 H4226H 1

BEARING

ﾍﾞｱﾘﾝｸﾞ #6001ZZ OT

187 CLN8690 1 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T-2ｶﾞﾀ OT

188 N4026A 2

SCREW, HEX SOCKET SET

ﾈｼﾞ六角穴止め

M4X4L FE

191 DBPP0650 1 BKT, MOTOR BKT ﾓｰﾀ
