17.基板リフタ(DBPQ) 17.Board lifter(DBPQ) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 42 DBPP0080 1 BKT BKT FE 43 H5299A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE 44 W1023…
17.基板リフタ(DBPQ)
17.Board lifter(DBPQ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DBPQ0010 1 BASE ﾍﾞｰｽ FE
2 H5360A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M10X25L FE
3 W1026A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M FE
4 DBPQ0020 2 SHAFT ｼｬﾌﾄ OT
5 DBPQ0031 1 PLATE ﾌﾟﾚｰﾄ AL
6 H5289A 16
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12 FE
7 H5276A 12
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
8 W1021A 12
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
9 DBPQ0040 1 PLATE ﾌﾟﾚｰﾄ AL
10 H5276A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
11 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
12 DBPQ0050 2 PLATE ﾌﾟﾚｰﾄ FE
13 DBPQ0060 1 GUIDE ｶﾞｲﾄﾞ FE
14 H5276A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
15 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
16 DBPQ0070 1 GUIDE ｶﾞｲﾄﾞ FE
17 H5276A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
18 W1021A 4 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
19 DBPQ0080 1 JOINT ｼﾞｮｲﾝﾄ FE
20 N1085A 1
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0 OT
21 N1088A 1
NUT, HEX
ﾅｯﾄ 六角
M6-L(全ﾈｼﾞ) OT
22 DBPQ0220 4 BKT BKT FE
23 H5290A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L FE
24 W1022A 8
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
25 W1043A 8 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
26 DBPP0010 1 KEY ｷｰ FE
27 DBPP0030 1 BKT BKT FE
28 H5331A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X45L FE
29 W1024A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
30 DBPP0040 1 BKT BKT FE
31 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
32 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
33 DBPP0050 1 DOG ﾄﾞｯｸﾞ FE
34 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
35 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
36 W1042A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
37 DBPP0060 1 DOG ﾄﾞｯｸﾞ FE
38 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
39 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
40 W1042A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
41 DBPP0071 4 ARM ｱｰﾑ FE
QP-351E-MM PARTS LIST
17 - 3
17.基板リフタ(DBPQ)
17.Board lifter(DBPQ)
17.基板リフタ(DBPQ)
17.Board lifter(DBPQ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
42 DBPP0080 1 BKT BKT FE
43 H5299A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
44 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
45 H5288A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L FE
46 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
47 DBPP0090 2 DOG ﾄﾞｯｸﾞ FE
48 H5290A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L FE
49 W1011A 2
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
50 DBPP0160 2 BKT BKT FE
51 H5276A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
52 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
53 DBPP0170 2 GUIDE ｶﾞｲﾄﾞ FE
54 DBPP0180 1 ARM ｱｰﾑ FE
55 N4019A 1
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X4 FE
56 DBPP0190 2 ARM ｱｰﾑ FE
57 N4019A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M3X4 FE
58 BHPP0070 2 PLATE ﾌﾟﾚｰﾄ FE
59 BHPP0100 4 GUIDE ｶﾞｲﾄﾞ FE
60 H5174A 4
BOLT, HEX
ﾎﾞﾙﾄ 六角 M4X40L(全ﾈｼﾞ) FE
61 N1080A 4
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7 FE
62 BHPP0220 1 PIN ﾋﾟﾝ FE
63 BHPP0230 1 BLOCK ﾌﾞﾛｯｸ FE
64 H5290A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L FE
65 BHPP0330 4 HOUSING ﾊｳｼﾞﾝｸﾞ FE
66 H5307A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X40L FE
67 W1012A 8
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
68 ABHPP8020 4 PIN, BACKUP ﾋﾟﾝ ﾊﾞｯｸｱｯﾌﾟ OT
69 BHPP0240 4 BKT BKT FE
70 H5299A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
71 BHPP0260 4 PIN, BACKUP ﾋﾟﾝ ﾊﾞｯｸｱｯﾌﾟ FE
72 IPB5960 6 KEY ｷｰ FE
73 NPT0700 1 KNUCKLE ﾅｯｸﾙ FE
74 NPT0710 1 KNUCKLE ﾅｯｸﾙ FE
75 NPT0770 2 PIN ﾋﾟﾝ FE
76 W1017A 1
WASHER, CONICAL
ﾜｯｼｬ 皿
M-14-H FE
77 Y3045L 6 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ TL6-01M OT
78 Y3045C 2 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ TLL6-01M OT
79 Y3117A 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ TS6-01M OT
80 H3118A 7 PLUG ﾌﾟﾗｸﾞ P-5M OT
81 Y30203 3 UNION ﾕﾆｵﾝ UT6M OT
82 A5091A 1
O RING
Oﾘﾝｸﾞ P7 OT
QP-351E-MM PARTS LIST
17 - 4
17.基板リフタ(DBPQ)
17.Board lifter(DBPQ)
17.基板リフタ(DBPQ)
17.Board lifter(DBPQ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
83 A5090A 1 O RING Oﾘﾝｸﾞ P6 OT
84 H2044A 2
PIN, SPRING
ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 2ﾟX15L OT
85 H3165A 2
PLUNGER, BALL
ﾌﾟﾗﾝｼﾞｬ ﾎﾞｰﾙ BST-4 OT
86 N1080A 2
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7 FE
87 K1138Z 4
COLLAR
ｶﾗｰ R10 OT
88 H5322A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X15L FE
89 W1024A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
90 S1024A 4
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-6 OT
91 H44291 2 BEARING, BALL ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LMR12UU OT
92 H5287A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
93 S40445 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX77(ｹｰﾌﾞﾙ2M) OT
94 H5276A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
95 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
96 H4391A 4
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA1520Z OT
97 H1050H 1
VALVE, CHECK
ﾊﾞﾙﾌﾞ ﾁｪｯｸ C250-01-16W OT
98 S2125Z 1
CYLINDER, AIR
ｼﾘﾝﾀﾞ ｴｱｰ CQ2D40-40DCM OT
99 N1001X 1 KNUCKLE ﾅｯｸﾙ Y-G04 OT
100 H1063G 2
VALVE, MECHANICAL
ﾊﾞﾙﾌﾞ ﾒｶﾆｶﾙ VM121-01-01 OT
101 H5296A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X40L FE
102 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
103 K1108A 4
CAM FOLLOWER
ｶﾑﾌｫﾛｱ CF04 OT
104 N1080A 4
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7 OT
105 W1022A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
106 W1061Z 4 WASHER, FLAT ﾜｯｼｬ 平 SSWA26-2.0 FE
107 H2092X 6
PIN, PARALLEL
ﾋﾟﾝ 平行 3ﾟX8 OT
108 H5179T 1 BOLT, HEX ﾎﾞﾙﾄ 六角 M6X8L FE
109 ABHPP8010 4 PIN, BACKUP ﾋﾟﾝ ﾊﾞｯｸｱｯﾌﾟ OT
110 BHPP0240 4 BKT BKT FE
111 H5299A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
112 BHPP0250 4 PIN, BACKUP ﾋﾟﾝ ﾊﾞｯｸｱｯﾌﾟ FE
113 H1189A 4
PAD
ﾊﾟｯﾄ VP-15RS OT
114 A4042A 8 ELBOW ｴﾙﾎﾞ PL6-M5M OT
115 T2063A 4
TUBE
ﾁｭｰﾌﾞ TU0604B-20 OT
116 S2170K 1 JOINT, ONE-TOUCH ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL6-M6M OT
117 N4036A 7
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M5X5L FE
118 W1011A 16
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
QP-351E-MM PARTS LIST
17 - 5
17.基板リフタ(DBPQ)
17.Board lifter(DBPQ)
