Tools, Consumables, Spare and Wear Par ts 26 Maintenance Manual SIPLACE SX1/SX2/DX1/DX2
Tools, Consumables, Spare and Wear Parts
Maintenance Manual SIPLACE SX1/SX2/DX1/DX2 25
SXDX12V1
For C&P20/A/M/P and CPP
Guiding plate long for 10xx/20xx
► Note: When using ceramic nozzles for the CPP, you need the
guide plate with function state 02.
03066508-xx
Cleaning box for ceramic nozzles, type 20xx/long (for CPP) 03076627-xx
Cleaning box ceramic nozzles type 10xx/long (for C&P20/A/M) 03055736-xx
Cleaning box ceramic nozzles type 40xx/long (for C&P20 P) 03107651-xx
Cleaning rack 10xx (for C&P20/A/M and CPP), if required 03071700-xx
For DLM
Guiding plate short 03029178-xx
Cleaning box for ceramic nozzles, type 9xx 03003183-xx
Cleaning box for ceramic nozzles, type 30xx 03087685-xx
Additionally required documentation Item no. Supplied in the
service box
Service Manual SX1/SX2/DX1/DX2 German:
00196496-xx
English:
00196497-xx
Maintenance Manual SIPLACE Placement Heads CPP, C&P, and
Twin
Maintenance Manual SIPLACE DLM Placement Heads
If required, manufacturer's documentation for the vacuum pump
See http://www.becker-international.com
If required, assembly instructions for vacuum pump SX1/SX2 00196614- xx
If required, maintenance manual for the WPC
If required, user manual for glue feeder ("Cleaning and Mainte-
nance" section)
00197218-xx
If necessary, the technical information on "New one-handed
grease gun with cartridge for greasing the gantry axes"
DE: TI2015-
07D03
EN: TI2015-
07E03
Spare parts Item no. Supplied in the
service box
Gas pressure shock absorber 08/19 175N 03057763-xx
Fan GCU 03060954-xx
Cover fan 1 part 03094598-xx
Lubrication nipple DIN71412-A-M6 – straight (tape cutter) 03036936-xx
Lubrication nipple DIN71412-B-M6 – 45° bent (X-, Y-axis) 03036943-xx
Pulley, complete (for flap covers) 03078561-xx
Tools Item no. Supplied in the
service box
Tools, Consumables, Spare and Wear Parts
26 Maintenance Manual SIPLACE SX1/SX2/DX1/DX2
Minor Maintenance
Maintenance Intervals for Minor Maintenance
Maintenance Manual SIPLACE SX1/SX2/DX1/DX2 27
4
4 Minor Maintenance
Minor Maintenance
4.1
4.1 Maintenance Intervals for Minor Maintenance
Maintenance Intervals for Minor Maintenance
1000 - Minor – [EMPTY] – SXDX12 V1 V2
2000 - Minor - Basic Machine – SXDX12 V1 V2
2100 - Minor - Component F eed-In - SXDX12 V1 V2 - [ EMPTY]
2200 - Minor - Optical Systems – SXDX12 V1 V2
2300 - Minor - Gantry – SXDX12 V1 V2
2400 - Minor - Conveyor - SXDX12 V1 V2
3000 - Minor - Nozzles/Nozzle Magazines
See also
1.3.2 Calculation of Maintenance Intervals [ ➙ 15]
Maintenance tasks
Base machine
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
Checking/Cleaning the Cover Fans 3 X
Checking the Fans on the GCUs 2 X
Maintenance tasks
Gantry
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
Checking and Cleaning the Magnetic Surfaces of
the X and Y Axes
2X
Cleaning the X Axis Loose Bearing and Contact
Surface
2X
Cleaning the Y Axis Loose Bearing and Contact
Surface
2X
Maintenance tasks
Conveyor
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
Vacuuming the Transport, Nozzle Changer and
Insert
1X
Maintenance tasks
Nozzles
Duration
[min]
Each
week
Every 3
months
Every 6
months
Every 12
months
Cleaning/Replacing the Ceramic Nozzles 2 X
Replacing the Plastic Nozzles 2 X
