SIPLACE Software Guide Version 101.xx 3 Graphical user interface Issue 05/03 EN 3.3 User interface - views and menus 33 NOTE The following 3 menu optio ns belong to the group of single functions. The single function s ar…

3 Graphical user interface SIPLACE Software Guide Version 101.xx

3.3 User interface - views and menus Issue 05/03 EN

Æ Click the Stop processing PCB function in the Mode menu.

The current placement operation is halted.

Æ Click the Transport position button.

The lift moves to the defined safety/transport position..

Feed tray 3

This allows you to define the level containing the wafflepack tray to be made available for place-

ment. 3

NOTE

The waffle pack changer must not be in the refill position when this function is carried out. 3

Æ Click the Feed tray button.

The following dialog box is displayed.

Æ In the text box, enter the number of the required level and confirm your entry with OK. The waf-

flepack changer moves the wafflepack tray from the selected level to the pick-up position.

NOTE

If a waffle pack tray is already in the pick-up position, it is first moved to its defined level. 3

SIPLACE Software Guide Version 101.xx 3 Graphical user interface

Issue 05/03 EN 3.3 User interface - views and menus

NOTE

The following 3 menu options belong to the group of single functions.

The single functions are used to execute specific actions following fatal errors as well as to set up

and test the machine since they allow you to address the various functional modules in a defined

manner. 3

SF gantry 1 F5 3

This is used to call the single functions for gantry 1. These can be used to, for example, test the

functions of the revolver head. 3

NOTE

Each of the two gantries can be addressed separately.

The functions are identical for both gantries. 3

SF gantry 2 F6 (only for SIPLACE CS) 3

Single functions for gantry 2 3

Conveyor 1 F7 3

This is used to call the single functions for PCB conveyor. These are used to test and set the func-

tional modules for PCB conveyor as well as to set the conveyor width. 3

3 Graphical user interface SIPLACE Software Guide Version 101.xx

3.3 User interface - views and menus Issue 05/03 EN

NOTE

The next two menu options belong to the group of vision functions.

These functions are used to teach and test fiducials, measure components and change compo-

nent package form data.

The vision functions cannot be executed at the "Operator" access level. 3

Teach fiducial F8 3

This menu item is used to call the functions for the processing of fiducials for PCB position recog-

nition.

For a more extensive description of the procedure refer to the "Vision functions" section of the op-

erating instructions and in the online Help system. 3

Test component F9 3

This menu item is used to call the functions for the processing of component package forms for

component centering.

For a more extensive description of the procedure refer to the "Vision Functions" section of the

operating instructions. 3

Start SITEST F10 3

This automatically starts the SITEST test program for machine set-up and calibration.

The user interface, together with the procedure for the execution of the functions, is described in

the separate User’s Manual for the SITEST test program. 3

NOTE

The SITEST test program cannot be started from the "Operator" access level. 3
