MEMO
0301-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
123
NL-1
RI-3211
1 630 102 7432 LEVER 1 755NL-010-001
2 630 101 2643 HOLDER 1 755NL-010-002
3 630 103 3808 PIN,LOCATE 1 755NL-010-003
4 630 110 3051 ASSY,HOLDER 1 755NL-010-004
5 630 103 2993 HOOK 1 755NL-010-005
6 630 002 8171 SPRING,TENSION 1 755NL-010-006
7 630 103 3129 GRIP 1 755NL-010-007
8 411 050 5004 SCR TRS 3X6 1 755NL-010-008
9 630 000 7510 BOLT,HEX-SCT 5 755NL-010-009
10 630 000 7619 BOLT,HEX-SCT 3 755NL-010-010
11 630 000 7602 BOLT,HEX-SCT 1 755NL-010-011
12 630 000 7633 BOLT,HEX-SCT 2 755NL-010-012
13 411 141 2806 WASHER SPR 3 6 755NL-010-013
14 411 141 3902 WASHER V 3X7X0.5 6 755NL-010-014
15 411 141 2905 WASHER SPR 4 6 755NL-010-015
16 411 141 4008 WASHER V 4X9X0.8 6 755NL-010-016
17 630 110 4072 ASSY,GUIDE 1 755NL-010-017
18 411 140 7901 SCR TRS 3X4 1 755NL-010-018
19 630 000 7503 BOLT,HEX-SCT 1 755NL-010-019
20 411 140 9905 NUT HEX 3 1 755NL-010-020
51 630 113 8138 ASSY,LAMP 1 755NL-010-051
MEMO
0301-002
125
Fig. Q テープフィーダ TAPE FEEDER
PF-
4410
PF-
4410
