USING YOUR EXPLODED ILLUSTRATION
USING YOUR EXPLODED ILLUSTRATION
This Exploded Illustration shows the information about the Optional Specifications of
SIGMA-G4/G5 and is made for Parts Ordering.
You must not replace a part with a new one according to only the information of this
Exploded Illustration.
1. Inquiring
For identification of each part, numbers are placed on illustration pages. These
numbers (Key No.) again appear in the far left column of the part table joined up
with the illustration.
The number shown in the Q’ty column of the part table represents the quantity of
certain part used in the equipment. In case of unit assembly, however, the number
represents the quantity of certain part contained in single unit.
2. Parts Ordering
For ordering parts, some parts might not be supplied as a single item, due to the
constitution of such parts.
When ordering parts, be sure to inform us of the following details:
Model Type
Serial No.
Fig. No.
Key No.
PART No.
PART NAME
Quantity
[Example]
3. Miscellaneous
This Exploded Illustration is subject to change without prior notice.
This Exploded Illustration shall not in any shape or form, in whole or part, be
reproduced, copied or disclosed to any third party without the written content
of the publisher.
'' NOTE '' is used to show the notice that is not directly related to safety.
Some of the parts shown in the Exploded Illustration could fall into the scope of your
government’s regulations on strategic products. In that case, anybody who intend to
export the product should acquire due authorization.
GS-HS100
Model Type
123456S 7890
Serial No.
Key No.7
Key No.
0916DM11
PART No. Q'ty
1
Fig. No.
Fig. A1-1
PART NAME
COVER
1010-001
CONTENTS-1
CONTENTS-1
GS-HS100
Fig. A1 MR12
ヘッド
MR12 HEAD
GS-NH150
Fig. A2 MR12
ノズルストッカ
MR12 NOZZLE STOCKER
