MACHINE CONTROL
CAN BUS
8.56 Technical Reference Manual Chapter Issue 4, Jun 18
N19SK17
N19SK18
N19SK6
Pin No. Signal Pin No. Signal
16
27
38
49
5
9 Way D Type Socket
1
6
Pin No. Signal Pin No. Signal
1 DIG OUT0 6 DIG OUT5
2 DIG OUT1 7 DIG OUT6
3 DIG OUT2 8 DIG OUT7
4 DIG OUT3 9 DIG OUT8
5DIG OUT4
9 Way D Type Socket
1
6
Pin No. Signal Pin No. Signal
1DIG OUT1 20V
2 Way Trident Connector
1
MACHINE CONTROL
CAN BUS
Chapter Issue 4, Jun 18 Technical Reference Manual 8.57
N19SK8
N19SK11
N19PL1 NODE POWER
Pin No. Signal Pin No. Signal
1DIG OUT2 20V
2 Way Trident Connector
1
Pin No. Signal Pin No. Signal
1DIG OUT3 20V
2 Way Trident Connector
1
Pin No. Signal Pin No. Signal
1 +24V 4 0V
20V 5+12V
3 +24V SW 6 0V
4
1
6 Way Trident Connector
MACHINE CONTROL
CAN BUS
8.58 Technical Reference Manual Chapter Issue 4, Jun 18
N19PL5 SOLID STATE SWITCHES
N19SK12
N19SK14
Pin No. Signal Pin No. Signal
1 +12V 7 +12V
2 DIG IN 4 8 DIG IN 6
30V 90V
4 +12V 10 +12V
5 DIG IN 5 11 DIG IN 7
6OV 120V
Pin No. Signal Pin No. Signal
1 DIG OUT4 3 DIG OUT 5
20V 40V
1
4 Way Trident Connector
Pin No. Signal Pin No. Signal
1 DIG OUT6 3 DIG OUT 7
20V 40V
1
4 Way Trident Connector
