MACHINE CONTROL CAN BUS 8.5 8 Tech ni cal Ref ere nce Ma nual Cha pter I ssue 4, Jun 18 N19PL5 SOLID ST A TE SWITCHES N19SK12 N19SK14 Pin No. Signal Pin No. Si gna l 1 +12V 7 +12V 2 DIG IN 4 8 DIG I N 6 30 V 90 V 4 +12V …
MACHINE CONTROL
CAN BUS
Chapter Issue 4, Jun 18 Technical Reference Manual 8.57
N19SK8
N19SK11
N19PL1 NODE POWER
Pin No. Signal Pin No. Signal
1DIG OUT2 20V
2 Way Trident Connector
1
Pin No. Signal Pin No. Signal
1DIG OUT3 20V
2 Way Trident Connector
1
Pin No. Signal Pin No. Signal
1 +24V 4 0V
20V 5+12V
3 +24V SW 6 0V
4
1
6 Way Trident Connector
MACHINE CONTROL
CAN BUS
8.58 Technical Reference Manual Chapter Issue 4, Jun 18
N19PL5 SOLID STATE SWITCHES
N19SK12
N19SK14
Pin No. Signal Pin No. Signal
1 +12V 7 +12V
2 DIG IN 4 8 DIG IN 6
30V 90V
4 +12V 10 +12V
5 DIG IN 5 11 DIG IN 7
6OV 120V
Pin No. Signal Pin No. Signal
1 DIG OUT4 3 DIG OUT 5
20V 40V
1
4 Way Trident Connector
Pin No. Signal Pin No. Signal
1 DIG OUT6 3 DIG OUT 7
20V 40V
1
4 Way Trident Connector
MACHINE CONTROL
CAN BUS
Chapter Issue 4, Jun 18 Technical Reference Manual 8.59
N19PL10 TRS SENSORS
N19SK4
N19SK13
Pin No. Signal Pin No. Signal
1 +12V 7 +12V
2 DIG IN 0 8 DIG IN 2
30V 90V
4 +12V 10 +12V
5 DIG IN 1 11 DIG IN 3
6OV 120V
Pin No. Signal Pin No. Signal
1 +12V 3 0V
2 DIG IN 3 4
1
3 Way Trident Connector
Pin No. Signal Pin No. Signal
1 +12V 3 0V
2 DIG IN 10 4
1
3 Way Trident Connector
