4. Safety Labels To warn the operator of hazards, safety labels are attached to the machine at the positions indicated in the figure below. Familiarize yourself with each label and its message before operating the machin…
3. Safety Rules for Individual Machine Types
NP-1-series Machines
Safety Guidelines
Edition 1.1 7 NP-134E/134ME Mechanical
WARNING
Do not insert hands or other body parts into the
conveyor inlets.
● Body parts may get caught in the machine resulting in injury.
Do not operate the machine when the covers have been
removed.
● Body parts may get caught in the machine resulting in injury.
Do not operate the machine after disabling the safety
switches.
● Do not operate the machine when the PFU has been removed and
the safety switches disabled. Body parts may get caught in the
machine resulting in injury. Always return the PFUs to their original
positions after removal.
● Do not short or remove the machine’s safety switches. Persons
working on the machine may be seriously injured if operation
commands are issued by mistake.
Do not move the PFU without first checking that nothing
lies in the direction of movement.
● Incorrect handling may cause injury or damage to personnel or
equipment.
Do not move the PFU by applying a sharp push and
then releasing the handle.
● Incorrect handling may cause injury or damage to personnel or
equipment.
4. Safety Labels
To warn the operator of hazards, safety labels are attached to the machine at the
positions indicated in the figure below.
Familiarize yourself with each label and its message before operating the machine.
Front Side (Side 1)
Note: The illustration above shows the example of the NP-134E.
NP1MZ050a
1
2
<WARNING>
DISCONNECT POWER PRIOR TO SERVICING.
3
<Caution>
Connect / Disconnect the connector
after turning off the power.
4
5
6
910
8
7
<Caution>
Use appropriate tap on transformer when
wiring power supply cable to primary side.
Never insert your hand
inside an operating machine.
Moving parts may cause injury.
DANGER
High Voltage Caution
1
1
1
2
3
5
6
6
5
1
1
9
8
10
7
4
1
1
Always lower the nozzle station
before moving the head.
CAUTION
1
Safety Guidelines
Edition 1.1 8 NP-134E/134ME Mechanical
Rear Side (Side 2)
Note: The illustration above shows the example of the NP-134E.
NP1MZ051a
1
5
6
Never insert your hand
inside an operating machine.
Moving parts may cause injury.
DANGER
High Voltage
Caution
1
1
1
1
5
6
5
1
9
10
8
7
9
10
8
7
Always lower the nozzle station
before moving the head.
CAUTION
6
Safety Guidelines
Edition 1.1 9 NP-134E/134ME Mechanical
