Placing Head PFU-4E <for NP-134E> NP1MN054 Waste tape box Device table NP1MN053 Mechanical valve Nozzle Part 1 Chapter 2 Machine Components Edition 1.0 1-2-4 NP-134E/134ME Mechanical
Inside the Machine
Note: The illustration above shows the example of the NP-134E.
NP1MN052
XY-robot 1
XY-robot 2
Mark cameras
Placing head 1
Placing head 2
In-conveyor
Nozzle station 2
Nozzle station 1
Out-conveyor
Reject parts box 2
Reject parts box 1
Panel lifter
Main conveyor
Part 1 Chapter 2 Machine Components
Edition 1.0 1-2-3 NP-134E/134ME Mechanical
Placing Head
PFU-4E <for NP-134E>
NP1MN054
Waste tape box
Device table
NP1MN053
Mechanical valve
Nozzle
Part 1 Chapter 2 Machine Components
Edition 1.0 1-2-4 NP-134E/134ME Mechanical
PFU-5E <for NP-134ME>
NP1MN054a
Waste tape box
Device table
Part 1 Chapter 2 Machine Components
Edition 1.0 1-2-5 NP-134E/134ME Mechanical
