Head 1 SX000 SX008 SX010 X050 X051 X052 X053 I1 AXIS HOME θ 1 AXIS HOME Z1 AXIS HOME NZL CATCH OK1 CHG NZL NOTHING1 ST16 NZL CHK1 NZL END OK1 I 1_ AXIS_ZERO θ 1_AXIS_ZERO Z1_ AXIS_ZERO NOZZLE CATCH CHECK1 CHENGER NOZZLE …
Y-Slide
SX040
SX042
SX050
SX052
X034
Y1 AXIS HOME
Y1 AXIS -OT
Y2 AXIS HOME
Y2 AXIS +OT
Y AXIS COLSION
Y1_AXIS_ZERO
Y1_AXIS_-OT
Y2_AXIS_ZERO
Y2_AXIS_+OT
Y AXIS COLLISION CHECK
NP1Tb052
Sensor No.
INDICATION SIGNAL NAME
NP1MN059
X034
SX052
SX050
SX042
SX040
(Side 2)
(Side 1)
Part 1 Chapter 4 Sensor Positions
Edition 1.0 1-4-3 NP-134E/134ME Mechanical
Head 1
SX000
SX008
SX010
X050
X051
X052
X053
I1 AXIS HOME
θ1 AXIS HOME
Z1 AXIS HOME
NZL CATCH OK1
CHG NZL NOTHING1
ST16 NZL CHK1
NZL END OK1
I 1_ AXIS_ZERO
θ1_AXIS_ZERO
Z1_ AXIS_ZERO
NOZZLE CATCH CHECK1
CHENGER NOZZLE EXIST CHECK1
16ST NOZZLE NORMAL POSITION CHECK1
NOZZLE END CHECK1
NP1Tb053a
Sensor No.
INDICATION SIGNAL NAME
SX000
SX010
X050 X052
X053
X053
X051
SX008
NP1MN060
Part 1 Chapter 4 Sensor Positions
Edition 1.0 1-4-4 NP-134E/134ME Mechanical
Head 2
SX020
SX028
SX030
X054
X055
X056
X057
I 2 AXIS HOME
θ2 AXIS HOME
Z2 AXIS HOME
NZL CATCH OK2
CHG NZL NOTHING2
ST16 NZL CHK2
NZL END OK2
I 2_ AXIS_ZERO
θ2_AXIS_ZERO
Z2 _ AXIS_ZERO
NOZZLE CATCH CHECK2
CHENGER NOZZLE EXIST CHECK2
16ST NOZZLE NORMAL POSITION CHECK2
NOZZLE END CHECK2
NP1Tb054
Sensor No.
INDICATION SIGNAL NAME
SX020
SX030
X056
X057
X057
X054
X055
NP1MN061
SX028
Part 1 Chapter 4 Sensor Positions
Edition 1.0 1-4-5 NP-134E/134ME Mechanical
