Body The information needed to understand the workings of the machine and how to perform maintenance is explained using text and illustrations. Page number A three digit hyphenated number appears in the footer on each pa…
Page Layout
Each page indicates the part number, chapter title, section title , manual name, page
number, and the edition number of the manual.
Part number
The part number to which each chapter belongs is shown on the header on each page.
Chapter number and title
The title of each chapter is shown in the header on each page. Each part may contain one
or more chapters.
Section title
Each chapter may be divided into several sections. The section number is composed of
the number of the chapter to which the section belongs, followed by a sequential number
for each section.
3. Replacing Consumable Parts
3.1 Replacing Nozzles
Point
A nozzle must be replaced when it becomes deformed or clogged to the point where
parts pick-up is adversely affected.
Procedure
WARNING
Always be sure to cut the main power before carrying out
any work.
While pulling the hook in the direction of the arrow, pull the nozzle out of the nozzle
holder as shown in the figure below.
Grip the new nozzle in the same manner and insert it into the nozzle holder until a
clicking sound is heard.
NP1MR050
Hook
Nozzle
Part 3 Chapter 3 Replacing Consumable Parts
Edition 1.0 3-3-1 NP-153E/153E-XL Mechanical
Chapter title
Chapter titlePart title
Section title
Main body
Edition number Page number Manual name
NP1MF001
About this Manual
Edition 1.1 ii NP-134E/134ME Mechanical
Body
The information needed to understand the workings of the machine and how to perform
maintenance is explained using text and illustrations.
Page number
A three digit hyphenated number appears in the footer on each page. The first digit of
each page number indicates the part number, the second digit indicates the chapter
number within the part, and the final digit is the sequential page number within that
chapter. Page 1-2-1, for example, indicates that this is the first page in the second chapter
of part 1.
Manual name
The name of the manual that appears on the cover is also shown in the footer on each
page.
Edition number
The edition number is updated each time the manual is revised, with the number
reflecting the scale of changes that were made.
Minor revision: Minor changes are reflected in the part of the edition number after
the decimal point, for example, a change from edition 1.0 to 1.1. This
change is made on the revised pages only, and these pages can be
downloaded as required from Fuji's website.
Major revision: If major changes are made, the edition number is increased by one,
for example, a change from edition 1.0 to 2.0. This change is made on
all pages, including the cover.
Note: The reference numbers at the bottom right of the illustrations are for administrative
purposes only, and are in no way connected to the content of the manual.
About this Manual
Edition 1.1 iii NP-134E/134ME Mechanical
