2.2 In-conveyor Lubrication 1. Arrow marks in the illustrations indicate lubrication points. Black arrows indicate points where a grease gun is required. 2. Numbers shown in parentheses correspond to items on the checkli…
2.1 XY-Robot Lubrication (Y-axis LM Guides)
Note: The ball screws and LM guides on the X-axis, and the ball screws on the Y-axis are
self-lubricating.
1. Arrow marks in the illustrations indicate lubrication points.
Black arrows indicate points where a grease gun is required.
2. Numbers shown in parentheses correspond to items on the checklist provided at
the end of this chapter.
NP1ML058
(2)
(1)
(1)
(3)
(4)
(4)
Lubrication
Points
No.
Lubrication
Schedule
Daphne Eponex
No. 2
LM block
1 ~ 4
✔ Monthly
Table-001a
✔ : Lubricate N/A : Do not lubricate
Part 3 Chapter 2 Lubrication
Edition 1.1 3-2-4 NP-134E/134ME Mechanical
2.2 In-conveyor Lubrication
1. Arrow marks in the illustrations indicate lubrication points.
Black arrows indicate points where a grease gun is required.
2. Numbers shown in parentheses correspond to items on the checklist provided at
the end of this chapter.
NP1ML059
(9)
(6)
(11)
(11)
(12)
(10)
(10)
Shuttle
(5)
(7)
(8)
(8)
(13)
Lubrication
Points
Lubrication
Schedule
Daphne Eponex
No. 2
Ball screw
Shuttle
✔
Biral T&D
N/A
Every year
Table-002-1a
✔ : Lubricate N/A : Do not lubricate
No.
5
Shafts
✔ N/A
Every year
6, 7
Chain
N/A ✔
Every 6 months
8
Ball screw
✔ N/A
Monthly
9
LM block
✔ N/A
Monthly
10, 11
Shaft
✔ N/A
Monthly
12
Chain
N/A ✔
Every 6 months
13
Part 3 Chapter 2 Lubrication
Edition 1.1 3-2-5 NP-134E/134ME Mechanical
2.3 Out-conveyor Lubrication
1. Arrow marks in the illustrations indicate lubrication points.
Black arrows indicate points where a grease gun is required.
2. Numbers shown in parentheses correspond to items on the checklist provided at
the end of this chapter.
NP1ML060
(18)
(15)
(20)
(22)
(20)
(21)
(19)
(19)
Shuttle
(14)
(16)
(17)
(17)
Lubrication
Points
Lubrication
Schedule
Daphne Eponex
No. 2
Ball screw
Shuttle
✔
Biral T&D
N/A
Every year
Table-002-2a
✔ : Lubricate N/A : Do not lubricate
No.
14
Shafts
✔ N/A
Every year
15, 16
Chain
N/A ✔
Every 6 months
17
Ball screw
✔ N/A
Monthly
18
LM block
✔ N/A
Monthly
19, 20
Shaft
✔ N/A
Monthly
21
Chain
N/A ✔
Every 6 months
22
Part 3 Chapter 2 Lubrication
Edition 1.1 3-2-6 NP-134E/134ME Mechanical
