12 Segm. Collect & Place head DLM2 Page 25 / 26 24.11.2021 Pos. Item no. Description Part marking 175 00118021S01 COMPONENT SENSOR FOR 12 SEG. C+P HEAD SPARE PART 176 03018637S03 CO CAMERA C+P (TYPE 29) 27X27, DIG. R…
12 Segm. Collect & Place head DLM2
Page 24 / 26 24.11.2021
Pos. Item no. Description Part marking
(PLASTIC)
144 00359382-01 SPRING O-RING WEAR PART
145 00319748S04 12ER-SEGMENT CPL. DLM2 SPARE PART
146 00321451S01 RADIAL SPRING SPARE PART
147 03000896S01 AIR SUPPLY SPARE PART
148 00368211S02 DISTRIBUTOR DISK PAS-LX-12 ASSY SPARE PART
149 00341183S01 CONNECTION HOSE, DLM1 SPARE PART
150 00320023S01 O-RING 2.5X1 NBR 70 B WEAR PART
151 00303338-01 DIN 6325 - 1,5M5 X 5-ST
152 00322912-01 DIN912-M2 X 8-A2-70
153 00304316-01 DIN912-M2 X 3-A2-70
154 00201348-01 DIN 84-M1,6 X 4-A2
155 00325298S03 COVER F. READER BOARD
(PLACEMENT HEAD)
SPARE PART
157 03001821-01 BALL FOR SNAP FASTENER SPARE PART
158 00335990S06 DIGITALER ROTAY ENCODER C+P12
/ DLM
SPARE PART
159 03010450-01 COMPRESSED AIR TUBE BLAST AIR
V. / 2.5X4X220
160 00322562-01 DIN912-M2,5 X 4-A2-70
161 00308108-01 DIN912-M2,5 X 8-A2-70
162 00303193-01 DIN912-M3 X 8-A2-70
163 00337990-01 DIN912-M4 X 16-A2-70
167 00350588S04 12ER- SLEEVE WITH BALL FIXING
COMP.
SPARE PART
168 03037984-03 VAKUUM PLATE COMPL. DLM / R-
LIGHTBEIGE
WEAR PART
169 00322602-06 NOZZLE TYPE 704/904/3004 CPL. /
CERAMIC
WEAR PART
170 03001806-01 COVER IN FRONT COM. / DLM SPARE PART
171 00336426S01 SHEET METAL COVER F. REAR PART
DLM1/12
SPARE PART
172 00336427S01 ANTI-GLARE SHIELD FRONT
PANEL/DLM1
SPARE PART
173 00313069-01 DIN912-M4 X 10-A2-70
174 00845001-01 HEXAGON SOCKET HEAD CAP
SCREW M2 X 4-A2
00346483S01 VELCRO FASTENER STANDARD PARTS
12 Segm. Collect & Place head DLM2
Page 25 / 26 24.11.2021
Pos. Item no. Description Part marking
175 00118021S01 COMPONENT SENSOR FOR 12 SEG.
C+P HEAD
SPARE PART
176 03018637S03 CO CAMERA C+P (TYPE 29) 27X27,
DIG. RK
SPARE PART
03015967-02 PLATINE/VISION LED-TREIBER
SST28
03022098-01 CABLE ASSEMB /BE-CAMERA C+P
(TYP 28/29)
177 03014449S05 BE-CAMERA C+P (TYP28) 18X18
DIGITAL RK
SPARE PART
03015967-02 PLATINE/VISION LED-TREIBER
SST28
03062799S02 ROUND CABLE SET: C+P-CAM.
(TYPE28,29,38)
*
178 03010333-01 FIXING MATERIAL INTERFACE
BOARDS
03049176-01 UPGRADE KIT /DLM2 16-BITL
179 03037632-01 HEAD BOARD SET /DLM2 COMPL.
16-BIT
180 03019066-03 BOARD: HEAD ADAPTER DLM-X SPARE PART
181 00344488S03 SM BOARD MODULAR SPARE PART
182 03005194-01 CABLE SUPPORT HEAD ADAPTER
DLM2 CPLT.
SPARE PART
03003391-01 AXIS CONTROL FOR DLM2-HEAD
AXES
183 00353445S04 SERVO AMPLIFIER SDS120/2,5S1 SPARE PART
184 03002141S02 SERVO AMPLIFIER SDS60/3Z1 SPARE PART
185 03002142S02 SERVO AMPLIFIER SDS60/1D1 SPARE PART
03004333-01 FLAT RIBBON CABLE SET DLM SPARE PART
03004334-03 FLAT RIBBON CABLE DLM-BE SPARE PART
03048638-02 BOX SPARE PART
186 03011721-01 FIXING SET DLM2 AT HF
03006775-02 PIPING DLM2 HF-/X-SSERIES SPARE PART
03004490-01 TUBE 8X5 HOLDER CIRCLE HF
03004492-01 TUBE 6X4 PLACEMENT CIRCLE HF
03006728S01 PVC CAP TYP D DI8,0 H 15 10X SPARE PART
03006776-01 COOLING AIR TUBE
03006777-01 COOLING AIR TUBE X-MOTOR
00337891-01 PLUG QSC-6H
