12 Segm. Collect & Place head DLM2
Page 19 / 26 24.11.2021
12 Segm. Collect & Place head DLM2
Page 20 / 26 24.11.2021
Pos. Item no. Description Part marking
1 00367281-03 REVOLVER HAED DLM2-12 KPLT.
2 00367770S02 COLLECT & PLACE HEAD DLM2-12 /
WITHOUT C
Spare Part
3 00367769-01 FRONT PART COMPLETE DLM2
4 03000926-01 FONT PART DLM2 / FINISHED PART
5 03020626S02 STAR MOTOR C29 CPLT. Spare Part
6 03038908S01 Z-MOTOR WITH PCB SPARE PART
7 03001959S01 Z-AXIS CPL. DLM2 SPARE PART
8 00337640S01 1401GUIDE GEAR WHEEL, DLM1 SPARE PART
9 00367793S03 BLISTER UNIT DLM2/DLM3 SPARE PART
10 03001695-01 DISTRIBUTOR BLOCK /DLM2
11 00368050-01 THREADED JOINT SMC M-5ALN-4
12 00342849-02 TUBE 20/DLM1
13 03049879-01 TEE HOSE NIPPLE LO 3000-2.5 STANDARD PARTS
14 00342863-02 HOSE
15 00342850-02 TUBE 21/DLM1
16 00342861-02 TUBE 22/DLM1
17 03003526-03 MICRO SWITCHING VALVE BLOWING
UNIT 15V
SPARE PART
18 03050651-01 BANJO BOLT M5
19 03002197S01 DRIVER ARM ASSY SPARE PART
20 03002196S01 LIMIT BUFFER, DRIVER ARM DLM2
21 03034337S01 HANDLE ASSY SPARE PART
22 00319327S06 BEARING RACE /Z-AXIS
GUIDE/SEGM. GUIDE
SPARE PART
23 00359575-01 HOLDER SPARE PART
03039046S01 COVER Z-LIGHT BARRIER TOP II SPARE PART
25 00337715S01 MOTOR CLIP1 (Z-AXIS DRIVE), DLM1 SPARE PART
26 00343111S01 MOTOR CLIP2 (Z-AXIS DRIVE), DLM1 SPARE PART
27 00320965S02 STOP
28 00334801-01 ANGLE CLIP /DLM1
29 03043700S01 INSTEP LOCK / Z-AXIS SPARE PART
30 03002008S01 BLAST PIPE DLM2 SPARE PART
31 00329280S01 1401TUBE 2X0,2 SPARE PART
32 00334936S01 TOOTH BELT T2, DLM1 WEAR PART
12 Segm. Collect & Place head DLM2
Page 21 / 26 24.11.2021
Pos. Item no. Description Part marking
33 03053294S01 LIGHT BARRIER Z-AXIS TOP SPARE PART
34 00321524S05 SENSOR, Z-AXIS, BOTTOM SPARE PART
35 00330648S08 INTERMEDIATE DISTRIBUTOR
SP6/12 DIGITAL
SPARE PART
36 00355046S01 PLUG HOLDER 40 POLE STANDARD PARTS
37 00368063-01 CLIP, PANDUIT, CC S12-S08 D.3.1, B
8.2
STANDARD PARTS
38 00303472-01 DIN 84-M1,6 X 3-A2
39 00308973S01 DIN912-M1,6 X 4-A2-70
40 00845001-01 HEXAGON SOCKET HEAD CAP
SCREW M2 X 4-A2
44 00328906-01 DIN912-M3 X 5-A2-70
46 00303193-01 DIN912-M3 X 8-A2-70
56 00367765-02 12 SEGM. C+P HEAD BACK UNIT
CPL. DLM2/3
57 03000510-01 REAR PART DLM2-12 / FINISHED
PART
58 00341780S07 TURNING SYSTEM CPLT. DLM SPARE PART
59 03022671S02 DRIVE UNIT WITH SS-PINION
COMPL.
SPARE PART
60 00319387-03 MOTOR MOUNT
61 00320041S02 TOOTHED BELT SYNCHROFLEX 2.5
T2/90
WEAR PART
62 00319409-01 MOTOR CLAMP
63 00330573S01 DEJAMBOARD DP-MOTOR SPARE PART
64 00201465-01 CAP SCREW DIN84-M2X4-A2
65 00308973S01 DIN912-M1,6 X 4-A2-70
66 00845001-01 HEXAGON SOCKET HEAD CAP
SCREW M2 X 4-A2
67 00845004-01 HEXAGON SOCKET HEAD CAP
SCREW M2 X 8-A2
68 03065216S01 SWING TOP COMPL. / R2 SPARE PART
69 00320043S01 O-RING 16X2 E 70 B WEAR PART
70 03029481-02 ADJUSTMENT UNIT FOR ROTARY
STATION CPLT.
71 03041056-01 SILIKON TUBE FOR DRIVE ENGINE /
R
SPARE PART
72 03047191-01 CABEL TRACK / R
73 03048125S01 PUTTING UNITY F. TRICK STATION SPARE PART
