9
DEK FLEX NeoHorizon LPiX
Machine Standard Configuration
Services
Specification
Voltage
100 Volts to 240 Volts ±10%. Single phase 50/60 Hz
Maximum Current at 115V
15 Amps with vacuum pump
6 Amps without vacuum pump
Maximum Current at 230V
8 Amps with vacuum pump
3 Amps without vacuum pump
Over Current Protection
An external circuit breaker ≤20 Amps is required to be
fitted in line with the machine supply
Air Supply
To ISO 8573.1 Standard Quality Class 2.3.3
Pressure 5 bar to 8 bar
General usage 5 litres/minute at 5 bar to 8 bar
Maximum usage 226 litres/minute at 6 bar
Shipping Information
Specification
Approximate Weight
850kg boxed (dependent upon configured options
selected with machine)
690kg unboxed (dependent upon configured options
selected with machine)
Approximate Dimensions
2080mm x 1500mm x 1590mm High
(81.9” x 59” x 62.6”) Boxed
Certification
Specification
CE
98/37/EC
89/336/EEC
73/23/EEC
Subsequent amendments
Acoustic Noise Level
Less than 70dB 2003/1/EC
10
DEK FLEX NeoHorizon LPiX
Machine Productivity Package (included)
Process
Specification
Paste Control
Paste Dispenser (APDII or Jar Dispenser)
Paste Roll Height Monitor (PRHM 2)
Temperature/Humidity Sensor
Monitoring of the process environment
Data Capture
Specification
Product Data Capture
Verification & Traceability (Software only)
ProDEK closed loop (Software only)
Software & Communications
Specification
Software & Communications
Network files
Statistical Process Control
On board, reported via operator interface (QC-CALC)
11
DEK FLEX NeoHorizon LPiX
Machine Productivity Options
Process
Specification
Print Method
ProFlow® ATx
Stinger
Printing Environment Control
Contact PM
Recommended Stencil Frame
VectorGuard
Adjustable Width Stencil Mount (AWSM)
Frame variants – Fully adjustable to accommodate
frame sizes in the range of 381mm to 736mm
(15” to 29”) by 38mm height.
Image position: Centre/Front/Custom
Under Stencil Cleaning
Typhoon Under Stencil Cleaner, fully programmable
with wet/dry/vacuum wipe with external solvent tank
Specify length (300mm, 400mm, 460mm, 515mm)*
Vacuum Assist for Under Stencil
Cleaning
On board vacuum unit 35 litres/second airflow
Stencil Positioning
Automatic loading incorporating squeegee drip tray
* If configured with an AWSM, the cleaner chamber size should be matched with the minimum AWSM
width and stencil frame width being used
Handling & Cleaner Options
Specification
Substrate Handling Size (maximum)
620mm (X) x 508.5mm (Y) – Long Board Option
Under Stencil Cleaning
Typhoon Under Stencil Cleaner (620mm, poly blade
insert only)
Software & Communications
Specification
Substrate Handling
Flexible boards
Selective print pass through
Software & Communications
GEM on TCP/IP
