DEK FLEX NeoHorizon LPiX
Machine Productivity Package (included)
Process
Specification
Paste Control
Paste Dispenser (APDII or Jar Dispenser)
Paste Roll Height Monitor (PRHM 2)
Temperature/Humidity Sensor
Monitoring of the process environment
Data Capture
Specification
Product Data Capture
Verification & Traceability (Software only)
ProDEK closed loop (Software only)
Software & Communications
Specification
Software & Communications
Network files
Statistical Process Control
On board, reported via operator interface (QC-CALC)
11
DEK FLEX NeoHorizon LPiX
Machine Productivity Options
Process
Specification
Print Method
ProFlow® ATx
Stinger
Printing Environment Control
Contact PM
Recommended Stencil Frame
VectorGuard
Adjustable Width Stencil Mount (AWSM)
Frame variants – Fully adjustable to accommodate
frame sizes in the range of 381mm to 736mm
(15” to 29”) by 38mm height.
Image position: Centre/Front/Custom
Under Stencil Cleaning
Typhoon Under Stencil Cleaner, fully programmable
with wet/dry/vacuum wipe with external solvent tank
Specify length (300mm, 400mm, 460mm, 515mm)*
Vacuum Assist for Under Stencil
Cleaning
On board vacuum unit 35 litres/second airflow
Stencil Positioning
Automatic loading incorporating squeegee drip tray
* If configured with an AWSM, the cleaner chamber size should be matched with the minimum AWSM
width and stencil frame width being used
Handling & Cleaner Options
Specification
Substrate Handling Size (maximum)
620mm (X) x 508.5mm (Y) – Long Board Option
Under Stencil Cleaning
Typhoon Under Stencil Cleaner (620mm, poly blade
insert only)
Software & Communications
Specification
Substrate Handling
Flexible boards
Selective print pass through
Software & Communications
GEM on TCP/IP
12
DEK FLEX NeoHorizon LPiX
Machine Productivity Options
Transport
Specification
Substrate Support
Vacuum tooling capability
Vacuum tooling sensor
Vacuum cups
Grid-Lok® tooling
Substrate Transport
Single piece conveyor with flat belts (heavy boards)
Remote board stop (for use with heavy board option)
Substrate Fixture
All Purpose Clamping (APC) system*
Snuggers (edge clamping)
Foil-less clamps
* Can only be used with Modular single stage rail system – for availability contact product manager
Vision & Verfication
Specification
HawkEye® 750 Paste on Pad Verification
Enabled
HawkEye® 1700 Paste on Pad
Verification
Enabled (camera included)
HawkEye® Bridging
HawkEye® Bridging (requires HawkEye® 1700
camera)
Data Capture
Specification
Product Data Capture
Verification - handheld barcode reader
Traceability - remote barcode reader
