1 - 74
Student Guide SIPLACE X
3 Communication and Control Edition 09/2005
74
EEPROM write:
( e.g.Gantry 1 CAN ID 300 with C&P20)
CAN ID: 300 command: B3
31 00 12 01 write headinterface ID 01
CAN ID: 300 Acknowledge: B3 00
CAN ID: 300 command: B3
32 00 12 22 write headadapter ID 22
CAN ID: 300 Acknowledge: B3 00
CAN ID: 300 command: B3
33 00 12 30 write intermediate distributor ID 30
CAN ID: 300 Acknowledge: B3 00
CAN ID: 300 command: B3
35 00 12 31 write vacuumsensor holding circuit ID 31
CAN ID: 300 Acknowledge: B3 00
e.g. Gantry 1 Vision Board:
CAN ID: 180 command: B3
11 00 12 11 write Vision Board ID 11
CAN ID: 180 Acknowledge: B3 00
e.g. Gantry 3 Vision Board stationary:
CAN ID: 150 command: B3
11 00 12 12 write Vision Board stationary ID 12
CAN ID: 150 Acknowledge: B3 00
1 - 75
Student Guide SIPLACE X
Edition 09/2005 3 Communication and Control
75
3.6.4.1 Error messages TQM Modul
The error messages appears on the 7 segment display and in Caccia, with the SW 601.02 on the
station, too.
Error messages TQM Modul
E = Error
Description
E A0 (generell)
No HW found with the correct ID ( Vision, C600, C500,
Adapter oder Zwischenverteiler)
E 10 (Vision environment)
No Vision Board ID
E 11 (Vision environment)
EEPROM Data not plausible
E 12 (Vision environment)
EEPROM not available
E 20 (Twin Head environment)
No Twin Head HW found
E 61 (Twin Head environment)
EEPROM Data not plausible
E 62 (Twin Head environment)
EEPROM not available
E 68 (Twin Head environment)
Head Interface(C500) TQM Modul available --> remove the
TQM or set to RESET.
E 30 (C500 Head interface environment)
No C500 PCB found (HW)
E 50 (C500 Head interface environment)
more than one EEPROM‘s not available
E 51 (C500 Head interface environment)
EEPROM Data not plausible ( board type recognition data
Adapter and Intermediate distributor not conform)
E 52 (C500 Head interface environment)
board type recognition head interface (C500) not correct
E 53 (C500 Head interface environment)
board type recognition head adapter not correct
E 54 (C500 Head interface environment)
board type recognition intermediate distributor not correct
E 55 (C500 Head interface environment)
EEPROM not available headinterface (C500)
E 56 (C500 Head interface environment)
EEPROM not available head adapter
E 57 (C500 Head interface environment)
EEPROM not available or TQM on headinterface (C500)
not available
E 58 (C500 Head interface environment)
8 bit Procssor on headadapter available or remove the 8
bit processor
