● Open the horizontal tensioners (item 11)
● Pull the two actuating tubes (item 6) towards you at the same time and lift
up the bracket (item 7) to lock the raised component table bed in its top
end position.
● Hold down the button (item 5) for raising the component table bed (item 4)
until the component table bed reaches its top end position.
● Unplug the component table power cable (item 2).
● Unplug the component table control cable (item 1).
● Disconnect the compressed air supply (item 3).
● Remove the component table.
Docking the component table
WARNING
Check that the placement head is outside the range of the component
table.
CAUTION
When docking the component table, ensure that the table bed is in its top
end position and the bracket (item 7) is folded up.
● Cut off the empty tapes for the feeder modules.
● Make sure that the contact surface (item 10) for the component table bed
is clean.
● CAREFULLY push the component table into the placement system.
● Connect the compressed air supply (item 3).
● Plug in the control cable (item 1).
● Plug in the power cable (item 2) for the component table.
● Pull the two actuating tubes (item 6) towards you at the same time and
then lower the bracket (item 7) in order to be able to lower the component
table bed.
● Check that the centEring holes in the component table bed lie precisely
over the centering pins of the placement system.
● Hold down the button (item 5) until the component table bed reaches its
top end position.
● Release the button and the component table bed will descend.
● Ensure that the centring pins engage in the centring holes in the compo-
nent table bed and that the component table bed is fully lowered.
● Fold up the bracket (item 7) of the component table.
● Lock the two horizontal tensioners (item 11).
● Close the side screens and protective cover.
● Press the Start button to start the placement system.
