2-68
2
Board Explorer
4
Set the number of boards to be produced.
In the COUNT column, enter the number of boards to be produced and press the [Enter] key.
Setting the number of boards
64255-S0-00
5
Save the production plan file.
After the production plan setting is complete, save the production plan file in either of the following
formats.
●
YGOS1.xx
Select "Save YGOS1.xx" from the File menu or click the [Save YGOS1.xx] button (black) on the
toolbar. Then follow the instructions that appear.
●
YGOS2.xx
Select "Save YGOS2.xx" from the File menu or click the [Save YGOS2.xx] button (blue) on the toolbar.
The "Save As" dialog box then appears. Enter the file name, check the destination to save the file,
and click the [Save] button.
Saving the production plan file
YGOS2.xx format
Specify the save destination.
Enter the file name.
64256-S0-00
2-69
2
Board Explorer
7. Creating the backup folders
The Factory Tools allows you to create backup folders under any desired directory to back up board data. To
create backup folders, follow these steps.
1
Start the Board Explorer.
2
Select “Create Backup Folder” from the Data menu.
The "Browse for Folder" dialog box appears.
Data menu
Selecting "Create Backup Folder"
64257-S0-00
3
Specify the backup folder.
1. Select the directory to create a backup folder.
For example, if creating backup folders in drive "USB memory device", then select drive "USB memory
device" and click the [OK] button.
The "Browse for Folder" dialog box
64258-S0-00
c
CAUTION
CD-R drive and CD-RW drive cannot be specified to create backup folders.
2-70
2
Board Explorer
2. The "Create Backup Folder" dialog box appears. Click the [OK] button.
"Create backup Folder" dialog box
64259-S0-00
3. Backup folders for all registered lines have now been created in the selected drive (USB memory
device in this example).
Backup folders
Created backup folders
64260-S0-00
Reference
For details of how to store data in the backup folders, see the next section 6, "Managing the board data", in this
chapter.
