Chapter 3 Board Editor Contents 1. Board Editor 3- 1 1.1 Starting the Board Editor 3- 1 1.2 Quitting the Board Editor 3- 3 2. Basic operation 3- 4 2.1 Board Editor main window 3- 4 2.2 Board data window 3-1 1 2.3 Main vi…
2-84
2
Board Explorer
10.2.2 Multi-Combined Program
It is able to combine the board data for same board and both side. It is active only on line with dual lane
machine and some single board data are selected on main view. The mount mode (Parallel or Alternate) is set
automatically from the parts arrangement.
1
Displaying the “Board Data Combine” dialog
Select the main view board data and select “Multi Lane Utility” – “Multi-Combined Program” from the
right-click context menu to display the “Board Data Combine” dialog.
2
Combined board data name entry
Enter the name for the combined board data and click the [Combine] button.
“Board Data Combine” dialog
Changeable
642F7-S0-00
10.2.3 Divide Combined Program
It is able to divide the combined board data. It is active only when the combined board data is elected on main
view.
1
Displaying the “Divide Combined Program” dialog
Select the main view board data and select “Multi Lane Utility” – “Divide Combined Program” from the
right-click context menu to display the “Divide Combine Program” dialog.
2
Enter the names for the divided board data.
Enter the names for the divided board data in "Board name" and click the [Divide] button.
“Divide Combined Program” dialog
Enter the names for the
divided board data
642F8-S0-00
Chapter 3 Board Editor
Contents
1. Board Editor 3-1
1.1 Starting the Board Editor 3-1
1.2 Quitting the Board Editor 3-3
2. Basic operation 3-4
2.1 Board Editor main window 3-4
2.2 Board data window 3-11
2.3 Main view and detail view display manipulation 3-14
2.4 Manipulating the detail view 3-18
2.5 Working with multiple windows 3-20
2.6 Working with multiple board data 3-22
2.6.1 Arranging the Board Editor windows 3-22
2.7 Moving the cursor from one row to another (jump) 3-25
2.7.1 Moving the cursor to a specified line 3-25
2.7.2 Moving the cursor to the top line 3-26
2.7.3 Moving the cursor to the bottom line 3-26
2.7.4 Moving the cursor one row up or down 3-26
2.8 Copying and pasting the data 3-27
2.9 Filtering the data 3-29
2.9.1 Filtering the data 3-29
2.9.2 Canceling the filter 3-30
2.10 Search and replace 3-31
2.10.1 Search 3-31
2.10.2 Replace 3-33
2.10.3 Function of Replacing Data with Note 3-35
2.11 Data sorting 3-38
2.11.1 How to operate 3-38
2.11.2 Renumber Function 3-39
3. Graphic View 3-41
3.1 Displaying/closing the graphic view 3-41
3.2 Manipulating the graphic view 3-42
3.3 Editing the graphic view 3-45
3.3.1 Crating new mount information 3-45
3.3.2 Changing the mount positions 3-45
3.4 Board Graphic View Offset setting 3-47
4. Multi Lane Support 3-51
4.1 Board data select dialog is extended 3-51
