9. DIMENSIONS 9 - 4 (c) MR-J4-70B (-RJ)/MR-J4-100B(-RJ) [Unit: mm] 12 42 6 6 PE 12 CNP1 CNP2 CNP3 168 161 156 66 60 185 Lock knob Approx. 21 With MR-BAT6V1SET Approx. 80 Co o lin g f a n air intake Exhaust Approx. 69.3 A…
9. DIMENSIONS
9 - 3
(b) MR-J4-40B(-RJ)/MR-J4-60B(-RJ)
[Unit: mm]
170
156
161
168
40
66
6
CNP1
CNP2
CNP3
5
6
PE
Lock knob
With MR-BAT6V1SET
Approx. 38.5
Approx. 21
Approx. 69.3
Approx. 80
Mass: 1.0 [kg]
PE
Terminal
Screw size: M4
Tightening torque: 1.2 [N•m]
L2
N-
P3
L11
L21
P4
L3
L1
C
D
P+
CNP1
CNP2
V
W
U
CNP3
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
156 0.5
Approx. 4
0
2-M5 screw
Mounting hole process drawing
Approx.
6
Approx. 168
Approx.
6
Approx. 6
9. DIMENSIONS
9 - 4
(c) MR-J4-70B(-RJ)/MR-J4-100B(-RJ)
[Unit: mm]
12
42
6
6
PE
12
CNP1
CNP2
CNP3
168
161
15666
60 185Lock knob
Approx. 21
With MR-BAT6V1SET
Approx. 80
Cooling fan
air intake
Exhaust
Approx. 69.3
Approx. 38.5
Mass: 1.4 [kg]
PE
Terminal
Screw size: M4
Tightening torque: 1.2 [N•m]
L2
N-
P3
L11
L21
P4
L3
L1
C
D
P+
CNP1
CNP2
V
W
U
CNP3
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
156 ± 0.5
42 ± 0.3
3-M5 screw
Mounting hole process drawing
Approx. 6
Approx. 6
Approx. 168
Approx. 6
Approx. 60
Approx. 12
9. DIMENSIONS
9 - 5
(d) MR-J4-200B(-RJ)
[Unit: mm]
6
6
78 6
168
156 66
45
CNP1
CNP2
CNP3
90
85
195
161
6
PE
L
o
c
k
k
n
o
b
With MR-BAT6V1SET
Approx. 21
Cooling fan
air intake
Exhaust
Approx. 38.5
Approx. 69.3
Approx. 80
Mass: 2.1 [kg]
PE
Terminal
Screw size: M4
Tightening torque: 1.2 [N•m]
L2
N-
P3
L11
L21
P4
L3
L1
C
D
P+
CNP1
CNP2
V
W
U
CNP3
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
3-M5 screw
78 ± 0.3
156 ± 0.5
Mounting hole process drawing
Approx. 6 Approx. 6
Approx. 168
Approx. 90
Approx. 6 Approx. 6
