9. DIMENSIONS 9 - 15 (e) MR-J4-700B4(-RJ) [Unit: mm] 172 160 6 6 7.5 285 6 300 7.5 200 6 102.1 82 148.7 TE2 TE3 TE1 PE 27 15.5 14.5 11 46.5 13 13 4 23.6 50.1 25 26 3 × 13 (= 39) Built- in r egene rati ve res istor lead t…
9. DIMENSIONS
9 - 14
(d) MR-J4-500B4(-RJ)
[Unit: mm]
6 118
130
7.5235
7.5
250
200
TE2
TE3
TE1
6
81.5
4
28
52.8
106.6
141.2
6
37.8 13
11
13
26
26.6
28.6
18.3
15.4
3 × 13 (= 39)
PE
Built-in regenerative
resistor lead terminal
fixing screw
Cooling fan exhaust
With
MR-BAT6V1 SET
Intake
Terminal block layout
Approx. 28
Approx. 80
Mass: 4.3 [kg]
TE1
TE2
PE
TE3
PE
N- P3 P4TE3
L2 L3L1 CP+TE1 V WU
L11 L21TE2
Terminal
Screw size: M4
Tightening torque: 1.2 [N•m]
Screw size: M3.5
Tightening torque: 0.8 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
235 ± 0.5
118 ± 0.5
Mounting hole process drawing
Approx.
7.5
Approx.
7.5
Approx. 250
4-M5 screw
Approx. 6Approx. 6
Approx. 130
9. DIMENSIONS
9 - 15
(e) MR-J4-700B4(-RJ)
[Unit: mm]
172
160 66
7.5 285
6
300
7.5
200
6
102.1
82
148.7
TE2
TE3
TE1
PE
27
15.5
14.5
11
46.5
13
13
4
23.6
50.1
25 26
3 × 13 (= 39)
Built-in regenerative resistor
lead terminal fixing screw
Terminal block layout
With
MR-BAT6V1 SET
Intake
Approx. 28
Approx. 80
Cooling fan exhaust
Mass: 6.5 [kg]
TE1
TE2
PE
TE3
PE
N-TE3 P3 P4
L2 L3L1 CP+TE1 V WU L11 L21TE2
Screw size: M4
Tightening torque: 1.2 [N•m]
Screw size: M3.5
Tightening torque: 0.8 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
Terminal
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
0.5160
Approx. 300
285 0.5
Mounting hole process drawing
Approx.
7.5
Approx.
7.5
4-M5 screw
Approx. 6Approx. 6
Approx. 172
9. DIMENSIONS
9 - 16
(f) MR-J4-11KB4(-RJ)/MR-J4-15KB4(-RJ)
[Unit: mm]
260
10.5
220
196 1212
6
400
38010
10
TE1-1
25.5
57.9
5 × 25.5 (= 127.5)
22.8
PE
TE2
1124.2
4360
78.5
TE1-2
188
237.4
224.2
77
70.7
Approx. 28
With
MR-BAT6V1 SET
Approx. 80
Cooling fan exhaust
Intake
Terminal block layout
Mass: 13.4 [kg]
TE1-2
TE2
Screw size: M6
Tightening torque: 3.0 [N•m]
Screw size: M4
Tightening torque: 1.2 [N•m]
PE
TE1-1
PE
Screw size: M6
Tightening torque: 3.0 [N•m]
Screw size: M6
Tightening torque: 3.0 [N•m]
TE1-1
TE1-2
L11
L21
TE2
Terminal
L1 L2 L3 VW
CN-P4P+
U
P3
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
380 0.5
Approx. 12
A
pprox. 1
2
Mounting hole location diagram
Approx.
10
Approx. 400
A
pprox.
10
Approx. 22
0
4-M5 screw
0.5196
