11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 64
11.8.4 MR-BT6VCASE battery case
POINT
The battery unit consists of an MR-BT6VCASE battery case and five MR-
BAT6V1 batteries.
For the specifications and year and month of manufacture of MR-BAT6V1
battery, refer to section 11.8.5.
MR-BT6VCASE is a case used for connecting and mounting five MR-BAT6V1 batteries. A battery case does
not have any batteries. Please prepare MR-BAT6V1 batteries separately.
(1) The number of connected servo motors
One MR-BT6VCASE holds absolute position data up to eight axes servo motors. For direct drive motors,
up to four axes can be connected. Servo motors and direct drive motors in the incremental system are
included as the axis Nos. Linear servo motors are not counted as the axis Nos. Refer to the following
table for the number of connectable axes of each servo motor.
Servo motor Number of axes
Rotary servo motor 0 1 2 3 4 5 6 7 8
Direct drive motor 4 4 4 4 4 3 2 1 0
(2) Dimensions
[Unit: mm]
Mounting hole process drawing
2-M4 screw
Approx. 25
Approx. 130
Approx.5
Approx. 5
120 ± 0.5
5
5
5
130Approx. 70
25
130
4.6
1205
2- 5 mounting
hole
Mounting screw
Screw size: M4
[Mass: 0.18 k
g
]
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 65
(3) Battery mounting
POINT
One battery unit can be connected to up to 8-axis servo motors. However, when
using direct drive motors, the number of axes of the direct drive motors should
be up to 4 axes. Servo motors and direct drive motors in the incremental system
are included as the axis Nos. Linear servo motors are not counted as the axis
Nos.
The MR-J4W_-_B servo amplifiers can be combined with MR-J4-_B_(-RJ) servo
amplifiers. However, it cannot be used for MR-J4W2-0303B6.
(a) When using 1-axis servo amplifier
CN1A
CN1B
Cap
CN4
CN10
MR-BT6VCASE
MR-BT6V1CBL_M
Servo amplifier
(b) When using up to 8-axis servo amplifiers
CN4
CN10
MR-BT6VCASE
MR-BT6V1CBL_M
MR-BT6V2CBL_M
Servo amplifier
(Last)
MR-BT6V2CBL_M
Servo amplifier
(First)
CN4 CN4
Servo amplifier
(Second)
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 66
(4) Battery replacement procedure
WARNING
Before replacing a battery, turn off the main circuit power and wait for 15 minutes
or longer until the charge lamp turns off. Then, check the voltage between P+ and
N- with a voltage tester or others. Otherwise, an electric shock may occur. In
addition, when confirming whether the charge lamp is off or not, always confirm it
from the front of the servo amplifier.
CAUTION
The internal circuits of the servo amplifier may be damaged by static electricity.
Always take the following precautions.
Ground human body and work bench.
Do not touch the conductive areas, such as connector pins and electrical parts,
directly by hand.
POINT
Replacing battery with the control circuit power off will erase the absolute
position data.
Before replacing batteries, check that the new battery is within battery life.
Replace the battery while only control circuit power is on. Replacing battery with the control circuit power
on triggers [AL. 9F.1 Low battery]. However, the absolute position data will not be erased.
