11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 95
11.16 EMC f
ilter (recommended)
POINT
For when multiple servo amplifiers are connected to one EMC filter, refer to
section 6.4 of "EMC Installation Guidelines".
It is rec
ommended that one of the following filters be used to comply with EN EMC directive. Some EMC
filters have large in leakage current.
(1) Combination with the servo amplifier
Servo amplifier
Recommended filter (Soshin Electric)
Mass [kg]
Model Rated current [A]
Rated voltage
[VAC]
Leakage current
[mA]
MR-J4-10B(-RJ) to
MR-J4-100B(-RJ)
HF3010A-UN
(Note)
10
250
5
3.5
MR-J4-200B(-RJ)
MR-J4-350B(-RJ)
HF3010A-UN
(Note)
30 5.5
MR-J4-500B(-RJ)
MR-J4-700B(-RJ)
HF3040A-UN
(Note)
40
6.5
6
MR-J4-11KB(-RJ)
MR-J4-15KB(-RJ)
MR-J4-22KB(-RJ)
HF3100A-UN
(Note)
100 12
MR-J4-60B4(-RJ)
MR-J4-100B4(-RJ)
TF3005C-TX 5
6
MR-J4-200B4(-RJ) to
MR-J4-700B4(-RJ)
TF3020C-TX 20
500 5.5
MR-J4-11KB4(-RJ) TF3030C-TX 30 7.5
MR-J4-15KB4(-RJ) TF3040C-TX 40
12.5
MR-J4-22KB4(-RJ) TF3060C-TX 60
MR-J4-10B1(-RJ) to
MR-J4-40B1(-RJ)
HF3010A-UN
(Note)
10 250 5 3.5
Note. To use an
y
of these EMC filters, the sur
g
e protector RSPD-500-U4
(
Oka
y
a Electric Industries
)
is required.
Servo amplifier
Rec
ommended filter (COSEL)
Mass [kg]
Model Rated current [A]
Rated voltage
[VAC]
Leakage current
[mA]
MR-J4-11KB(-RJ) to
MR-J4-22KB(-RJ)
FTB-100-355-L
(Note)
100 500 40 5.3
MR-J4-22KB4(-RJ)
FTB-80-355-L
(Note)
80 500 80 5.3
Note. To use an
y
of these EMC filters, the sur
g
e protector RSPD-500-U4
(
Oka
y
a Electric Industries
)
is required.
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 96
(2) Conn
ection example
(a) For 3-phase 200 V AC to 240 V AC power supply
MCCB
1
2
3
123
MC
L1
L2
L3
L11
L21
4
5
6
MCCB
Servo amplifier
Surge protector
(Note)
3-phase
200 V AC to
240 V AC
EMC filter
Note. When a sur
g
e protector is used.
(b) F
or 1-phase 200 V AC to 240 V AC power supply
1
2
3
123
MC
L1
L2
L3
L11
L21
4
5
6
MCCB
Servo amplifier
Surge protector
(Note)
3-phase
200 V AC to
240 V AC
EMC filter
Note. When a sur
g
e protector is used.
(c)
For 3-phase 380 V AC to 480 V AC power supply
MCCB
1
2
3
123
MC
L1
L2
L3
L11
L21
4
5
6
MCCB
Servo amplifier
Surge protector
(Note)
3-phase
380 V AC to
480 V AC
EMC filter
Note. When a sur
g
e protector is used.
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 97
(d) F
or 1-phase 100 V AC to 120 V AC power supply
1
2
3
123
MC
L1
L11
L21
4
5
6
MCCB
L2
Servo amplifier
Surge protector
(Note)
1-phase
100 V AC to
120 V AC
EMC filter
Unassigned
Note. When a sur
g
e protector is used.
(3) Dim
ensions
(a
) EMC filter
HF3010A-UN
[Unit: mm]
32 ± 2
85 ± 2
110 ± 4
258 ± 4
273 ± 2
288 ± 4
300 ± 5
M4
IN
3-M4
65 ± 4
Approx. 41
4-5.5 × 73-M4
