11. OPT I ONS AND PER IPH ERA L EQU IPM ENT 11 - 9 7 (d) F or 1-phase 100 V AC to 1 20 V AC power s upply 1 2 3 123 MC L1 L1 1 L21 4 5 6 MCCB L2 Servo amplifier Surge protector (Note) 1-phase 100 V AC to 120 V AC EMC fil…
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 96
(2) Conn
ection example
(a) For 3-phase 200 V AC to 240 V AC power supply
MCCB
1
2
3
123
MC
L1
L2
L3
L11
L21
4
5
6
MCCB
Servo amplifier
Surge protector
(Note)
3-phase
200 V AC to
240 V AC
EMC filter
Note. When a sur
g
e protector is used.
(b) F
or 1-phase 200 V AC to 240 V AC power supply
1
2
3
123
MC
L1
L2
L3
L11
L21
4
5
6
MCCB
Servo amplifier
Surge protector
(Note)
3-phase
200 V AC to
240 V AC
EMC filter
Note. When a sur
g
e protector is used.
(c)
For 3-phase 380 V AC to 480 V AC power supply
MCCB
1
2
3
123
MC
L1
L2
L3
L11
L21
4
5
6
MCCB
Servo amplifier
Surge protector
(Note)
3-phase
380 V AC to
480 V AC
EMC filter
Note. When a sur
g
e protector is used.
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 97
(d) F
or 1-phase 100 V AC to 120 V AC power supply
1
2
3
123
MC
L1
L11
L21
4
5
6
MCCB
L2
Servo amplifier
Surge protector
(Note)
1-phase
100 V AC to
120 V AC
EMC filter
Unassigned
Note. When a sur
g
e protector is used.
(3) Dim
ensions
(a
) EMC filter
HF3010A-UN
[Unit: mm]
32 ± 2
85 ± 2
110 ± 4
258 ± 4
273 ± 2
288 ± 4
300 ± 5
M4
IN
3-M4
65 ± 4
Approx. 41
4-5.5 × 73-M4
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 98
HF3030A-
UN/HF-3040A-UN
[Unit: mm]
125 ± 2
44 ± 1
260 ± 5
140 ± 2
70 ± 2
140 ± 1
155 ± 2
3-M5
6-R3.25 length: 8
3-M5
M4
85 ± 1
210 ± 2
85 ± 1
HF3100A-
UN
[Unit: mm]
2-6.5 × 8
M8
145 ± 1
165 ± 3
M6
380 ± 1
400 ± 5
160 ± 3
M8
2-
φ
6.5
