11. OPT I ONS AND PER IPH ERA L EQU IPM ENT 11 - 100 TF3040C- TX/TF 3060C-TX [Unit: mm] 180 ± 2 Appr ox . 91.5 Approx. 190 200 ± 5 M6 390 ± 2 100 ± 1 412 ± 5 438 ± 5 Approx. 17 3-M6 22 22 8-R3.25 Length 8 (for M6) M4 M4 …
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 99
TF3005C-
TX/TX3020C-TX/TF3030C-TX
[Unit: mm]
290 ± 2
100 ± 1
308 ± 5
332 ± 5
Approx. 12.2
3-M4
16
6-R3.25 length 8 M4 M4
125 ± 2
140 ± 1
155 ± 2
IN
150 ± 2
Approx. 67.5
± 3
Approx. 160
170 ± 5
M4
3-M4
100 ± 1
16
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 100
TF3040C-
TX/TF3060C-TX
[Unit: mm]
180 ± 2
Approx.
91.5
Approx. 190
200 ± 5
M6
390 ± 2
100 ± 1
412 ± 5
438 ± 5
Approx. 17
3-M6
22 22
8-R3.25 Length 8 (for M6)
M4 M4
145 ± 2
3-M6
160 ± 1
175 ± 2
IN
100 ± 1 100 ± 1
11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 101
FTB
-100-355-L/FTB-80-355-L
[Unit: mm]
309
350
335 ± 0.5
2-φ6.5
80 ± 0.5
20
143 100
26
6.56.5
20
28
143
170
3-M8 (option-S: hexagon
socket head cap screw)
Output
Protective earth (PE)
M6 (option-S: hexagon
socket head cap screw)
Input
Protective earth (PE)
3-M8 (option-S: hexagon
socket head cap screw)
M6 (option-S: hexagon
socket head cap screw)
Terminal block coverTerminal block cover
Mounting hole
Mounting hole
Mounting plate
(Note)
Model
plate
Note. No heat radiation holes on the opposite face.
