其它检验
SLM120/120S/110 Maintenance Handbook 75
其它检验
消耗品更换清单
No Part Name Part Number Replacement Cycle Remark
1 NOZZLE ASSY AM03-000561A
2
AP5 R TOOL ASSY AM03-000410A
3
CALIBRATION_PLATE_ASSY_431 J90551240A
4
NOZZLE CN040 ASSY J9055134C
5
NOZZLE_CN400_ASSY J90551072A
6
PACKING_BOX_ASSY AM03-000572A
7
FUSE[250V 5A] EP10-900438
8
FUSE[250V 10A] EP10-900439
9
STEEL BALL [DIA2, SUS304] J7055140A
10
SILICON TUBE(BLACK) J72550021C
11
FILTER ELEMENT[LF-M5-60-Z-ELEMENT] J7458002A
12
FLAT_BELT-MAM_5P MAM-5P-1815 MC05-900188 以6个月为周期进行检验、如果异常则更换。
Technical Reference
参考
17
页
13
FLAT-BELT_MAM_5P_1815_02 MC05-900189 以6个月为周期进行检验、如果异常则更换。
Technical Reference
参考
21
页
14
ELEMENT_AIR TAF4000-05-6000 HP04-900025
15
ELEMENT_SEPARATOR PFH4000-0005A-6083 HP04-900024
ㅠㅠ
Chapter 6
其它检验
SLM120/120S/110 Maintenance Handbook 76
