The standard PCB conveyor height is 830 mm 15 mm. The standard overall height of the
machine is 1931 mm. For a PCB conveyor height of 950 mm (SMEMA option), this gives an
overall height of 2051 mm.
4.1.1 Transport configuration
The following components are not installed when the placement system is delivered from the fac-
tory:
– Keyboard
–Monitor
– Indicator lamp
– Component trolley
– Component barcode reader
4.1.2 Safety instructions
WARNING
Æ The applicable accident prevention regulations concerning the transportation of heavy goods
must be followed.
Æ In particular, you should wear safety boots to minimize the risk of crushing your feet.
Æ When you are transporting the machine, make sure that all the feet are clear of the floor. If they
are not clear, the feet will drag along the floor and bump into obstacles. This could damage the
machine foot thread in the machine frame.
Æ Attach the pallet jack only at the points identified by (A) in Fig. 4.1 - 1).
4.1.3 Means of transport
Use a pallet jack with the following specification to carry the machine:
Fork length: min. 1800 mm
Carrying power: min. 2000 kg
Clear width between forks: min. 350 mm 4
User Manual SIPLACE CS 4 Setting up the placement system
Software Version SR.408.xx 03/2006 US Edition 4.1 Transport configuration and infrastructure
101
4.1.4 Compressed air supply
4.1.4.1 Technical data
The technical data for the compressed air supply can be found in sections 3.3.2 and 3.3.3, page
66
.
4
4.1.4.2 Checking the compressed air supply
Check that the compressed air supply conforms to the prescribed machine specifications.
PLEASE NOTE:
The document entitled "Network configuration (electrical and compressed air) for SMD systems
on the customer's premises", item no. 00191409-xx, describes the action that can be taken to
meet the required specifications.
Æ Record the compressed air characteristics at the installation location.
4.1.5 Main power supply
4.1.5.1 Electrical ratings
The electrical ratings can be found in section 3.3.1, page 66.
4
4.1.5.2 Checking the main power supply
Check that the main power supply conforms to the prescribed machine specifications.
PLEASE NOTE:
The document entitled "Network configuration (electrical and compressed air) for SMD systems
on the customer's premises", item no. 00191409-xx, describes the action that can be taken to
meet the required specifications.
4 Setting up the placement system User Manual SIPLACE CS
4.2 Setting up the placement system Software Version SR.408.xx03/2006 US Edition
102
4.2 Setting up the placement system
4.2.1 Safety instructions
WARNING
– The applicable accident prevention regulations concerning the transportation of heavy goods
must be followed.
– There is a risk that the machine will tip over if you do not use the pallet jack specified in section
4.1.3
to transport the placement machine.
– In particular, you should wear safety boots to minimize the risk of crushing your feet.
– Attach the pallet jack only at the points identified by A in Fig. 4.1 - 1).
4.2.2 Setting up the placement machine
Æ Raise the placement system using the fork-lift truck and adjust the feet until there is a gap of
830 mm between the top edge of the PCB conveyors and the bottom edge of the feet.
Æ Leave a gap of 1 to 3 mm between the PCB conveyors of the placement system.
Æ Align all the placement systems exactly in line with one another. Use a cord pulled tight to en-
sure this.
Æ Adjust each placement system using a spirit level with an accuracy of 0.02 mm/m.
Æ Lock the feet in position.
Æ Check the placement system again using the spirit level and correct the settings, if necessary.
CAUTION
Make sure that you remove all the shipping braces from the placement system. 4
Æ Fit any components that were dismantled for dispatch.
Æ Connect all the electrical and pneumatic lines.
RISK OF DEATH
The electrical connection work MUST be carried out only by appropriately trained and certi-
fied personnel. 4
