3 Technical data User Manual SIPLACE CS 3.2 Electrical and pneumat ic connection points S oftware Version SR. 408.xx03/2006 US Edition 64 3.2 Electrical and pneuma tic connection point s 3 Fig. 3.2 - 1 Electrical and p n…
User Manual SIPLACE CS 3 Technical data
Software Version SR.408.xx 03/2006 US Edition 3.1 Description of the machine
63
3.1.1 Technical data - machine overview
3
*) The CS can be equipped to place 0201 components. Please consult the factory if you require this.
Placement procedure Collect&Place
Component range
*)
6-segment-Collect&Place head with
standard component vision camera
Max. component height
From 0,6 mm x 0,3 mm to 18,7 mm x 18,7 mm
(0201 to PLCC44, SO32, DRAM)
6 mm (10,7 mm available upon request)
Maximum placement rate (Benchmark)
with two 6-segment Collect&Place heads 20,000 comp/h
6-segment Collect&Place head
Angular accuracy
Placement accuracy
± 0.5° / 3 σ ± 0.7°/ 4 σ
± 68µm / 3 σ ± 90 µm / 4 σ
PCB format
(length x width) 50 mm x 50 mm to 508 mm x 460 mm
(2" x 2" to 20" x 18")
Long board: length up to 610 mm (24") (avail-
able upon request)
PCB thickness 0.5 mm to 4.5 mm
PCB changeover time 2.5 sec
Feeder capacity 118 tracks à 8 mm
Component supply
Feeder module types
Component trolley
Component tapes, stick magazines, bulk
cases, surf tapes (see section 6
)
Operating system Microsoft Windows XP / RMOS
Connection Inline or stand alone
Space required 4 m² / module
3 Technical data User Manual SIPLACE CS
3.2 Electrical and pneumatic connection points Software Version SR.408.xx03/2006 US Edition
64
3.2 Electrical and pneumatic connection points
3
Fig. 3.2 - 1 Electrical and pneumatic connection points on the placement system part 1
3
(1) Compressed air unit
(2) Connection for compressed air line
(3) Main power filter Z1
(4) Hole for power cable
(5) Service socket
(6) Compressed air connection for component trolleys
(7) Power supply connection for component trolley
(8) Communications connection for component trolley
User Manual SIPLACE CS 3 Technical data
Software Version SR.408.xx 03/2006 US Edition 3.2 Electrical and pneumatic connection points
65
WARNING
Never disconnect compressed air lines while they are pressurized. Risk of injury! 3
Fig. 3.2 - 2 Electrical and pneumatic connection points on the placement system part 2
(1) Main power switch
(2) Power supply connection for component trolley
(3) Communications connection for component trolley
(4) LAN connection (RJ45) in the control unit 45
WARNING
The placement system is supplied with 3 x 400 V~ or 3 x 208 V~ US version) ± 5%, 50/60 Hz
main power voltage. This means that some parts of the system carry potentially lethal voltages
- even when switched off at the main power switch. Death, serious injury or considerable damage
may result if this automatic placement system is handled incorrectly. 3
